09- Luggage Rack для BRP Ski-Doo GSX SPORT 500SS - 2008
-
№АртикулНазвание
-
1511000487 TrunkTrunk
-
2511000528 BracketBracket
-
3415018100 Rubber StopperRubber Stopper
-
4390401600 Pop Rivet 1/8''Pop Rivet 1/8''
-
5293150007 WasherWasher
-
6511000568 Trunk CoverTrunk Cover
-
7511000483 RH Tunnel RailRH Tunnel Rail
-
8293150104 Pop Rivet 3/16''Pop Rivet 3/16''
-
9520000646 Anchor LinkAnchor Link
-
10250000325 Torx Screw M6 X 12Torx Screw M6 X 12
-
11511000484 LH Tunnel RailLH Tunnel Rail
-
12293150104 Pop Rivet 3/16''Pop Rivet 3/16''
-
13520000646 Anchor LinkAnchor Link
-
14250000325 Torx Screw M6 X 12Torx Screw M6 X 12
-
15511000539 Rear Bag. Includes 15 to 16Rear Bag. Includes 15 to 16
-
16511000585 Fix ButtonFix Button
