TAILLIGHT(S) для Kawasaki KFX700 (KSV700-B1) - 2004 года выпуска
-
№АртикулНазвание
-
220220B0440 SCREW-PAN-CROSSCREW-PAN-CROS
-
1105111051-1870 BRACKET,TAIL LAMPBRACKET,TAIL LAMP
-
1106111061-0055 GASKET,TAIL LAMP LENSGASKET,TAIL LAMP LENS
-
1409114091-0095-6Z COVER,TAIL LAMP,F.BLACK (US ONLY)COVER,TAIL LAMP,F.BLACK (US ONLY)
-
14091A14091-0113-6Z COVER,TAIL LAMP,F.BLACK (CANADA ONLY)COVER,TAIL LAMP,F.BLACK (CANADA ONLY)
-
2302423024-1130 LAMP-ASSY-TAILLAMP-ASSY-TAIL
-
2302623026-1230 LENS,TAIL LAMPLENS,TAIL LAMP
-
2303623036-0001 BRACKET-TAIL LAMPBRACKET-TAIL LAMP
-
9200992009-1621 SCREW,6X16SCREW,6X16
-
9201592015-1678 NUT,CLAMP,6MMNUT,CLAMP,6MM
-
9202792027-1964 COLLAR,L=4.7COLLAR,L=4.7
-
9206992069-063 BULB,12V 21/5WBULB,12V 21/5W
-
9214392143-1087 COLLARCOLLAR
-
9216092160-1053 DAMPER,TAIL LAMPDAMPER,TAIL LAMP
-
9217292172-1061 SCREW,TAPPING,5X10SCREW,TAPPING,5X10
