METER(S) для Kawasaki KLR650 - 2003 года выпуска
-
№АртикулНазвание
-
1402414024-1407 COVER, METER CASE, LOWERCOVER, METER CASE, LOWER
-
2300823008-1332 SOCKET, ASSY., METERSOCKET, ASSY., METER
-
2500525005-1341 SPEEDOMETER, MPH (US ONLY)SPEEDOMETER, MPH (US ONLY)
-
25005A25005-1345 SPEEDOMETER, KPH (CANADA ONLY)SPEEDOMETER, KPH (CANADA ONLY)
-
2500925009-004 WASHER, 5.2X16X1.2WASHER, 5.2X16X1.2
-
2501525015-1263 TACHOMETER, X1000R/MINTACHOMETER, X1000R/MIN
-
2502325023-1152 COVER, METER CASE, UPPERCOVER, METER CASE, UPPER
-
2801128011-1091 METER, TEMPMETER, TEMP
-
9200992009-1163 SCREW, TAPPING, 4X16SCREW, TAPPING, 4X16
-
92009A92009-1172 SCREW, 2X6 (BLACK)SCREW, 2X6 (BLACK)
-
92009B92009-1293 SCREW, 3X22SCREW, 3X22
-
9206992069-1007 BULB, 12V 3.4W, T10BULB, 12V 3.4W, T10
-
92069A92069-1070 BULB, 12V 1.7W, T6.5BULB, 12V 1.7W, T6.5
-
9207592075-1581 DAMPER, METER BRACKETDAMPER, METER BRACKET
-
92075A92075-1890 DAMPERDAMPER
-
9207792077-1054 KNOB, METERKNOB, METER
-
9221092210-1124 NUT, 5MMNUT, 5MM
