RADIATOR для Kawasaki KLR650 - 2003 года выпуска
-
№АртикулНазвание
-
130130L0612 BOLT, FLANGEDBOLT, FLANGED
-
130A130L0620 BOLT, FLANGEDBOLT, FLANGED
-
130B130L0625 BOLT, FLANGEDBOLT, FLANGED
-
1100911009-1145 GASKET, RESERVOIR TANK CAPGASKET, RESERVOIR TANK CAP
-
1101211012-1084 CAPCAP
-
1403714037-1208 SCREENSCREEN
-
2700227002-1051 RELAY, ASSY.RELAY, ASSY.
-
2701027010-1167 SWITCH, FANSWITCH, FAN
-
3906039060-1074 RADIATORRADIATOR
-
3906239062-1125 HOSE, COOLINGHOSE, COOLING
-
39062A39062-1217 HOSE, COOLING, HEAD, RADIATORHOSE, COOLING, HEAD, RADIATOR
-
39062B39062-1220 HOSE, COOLING, RESERVOIRHOSE, COOLING, RESERVOIR
-
39062C39062-1243 HOSE, COOLING, RADIATOR, PUMPHOSE, COOLING, RADIATOR, PUMP
-
4307843078-1083 RESERVOIRRESERVOIR
-
4908549085-1066 CAP, ASSY., PRESSURECAP, ASSY., PRESSURE
-
49089A49089-1073-68 SHROUD, ENGINE (LEFT) (O.GREEN)SHROUD, ENGINE (LEFT) (O.GREEN)
-
49089C49089-1074-68 SHROUD, ENGINE (RIGHT) (O.GREEN)SHROUD, ENGINE (RIGHT) (O.GREEN)
-
5950259502-1082 FAN, ASSY.FAN, ASSY.
-
9200992009-1480 SCREW, 6X12SCREW, 6X12
-
92009A92009-1653 SCREW, 5X14SCREW, 5X14
-
9201592015-1487 NUTNUT
-
92015A92015-1758 NUT, 6MMNUT, 6MM
-
9202292022-1521 WASHER, NYLON, 5.3X11.5X1.5WASHER, NYLON, 5.3X11.5X1.5
-
9202792027-1920 COLLAR, L=14.1COLLAR, L=14.1
-
9203792037-147 CLAMP, TUBECLAMP, TUBE
-
9207192071-056 GROMMETGROMMET
-
9207592075-1352 DAMPERDAMPER
-
9215092150-1506 BOLT, FLANGED, 6X16BOLT, FLANGED, 6X16
-
9217092170-1033 CLAMP, COOLING HOSECLAMP, COOLING HOSE
