CHASSIS ELECTRICAL EQUIPMENT для Kawasaki NINJA ZX-12R - 2005 года выпуска
-
№АртикулНазвание
-
1105211052-1830 BRACKET, FUSEBRACKET, FUSE
-
1409114091-1499 COVER, JUNCTION BOXCOVER, JUNCTION BOX
-
2106121061-0001 RECTIFIERRECTIFIER
-
2600626006-1006 FUSE, 30A, GFUSE, 30A, G
-
26006A26006-1068 FUSE, 10A, RFUSE, 10A, R
-
26006B26006-1075 FUSE, 15AFUSE, 15A
-
2601126011-0037 WIRE, LEADWIRE, LEAD
-
26011A26011-1730 WIRE, LEAD, BATTERY (+)WIRE, LEAD, BATTERY (+)
-
26011B26011-1731 WIRE, LEAD, BATTERY (-)WIRE, LEAD, BATTERY (-)
-
26011C26011-1762 WIRE, LEAD, SUBWIRE, LEAD, SUB
-
26011D26011-1772 WIRE, LEAD (+)JUMP STARTWIRE, LEAD (+)JUMP START
-
2601226012-1334 BATTERY, YTX14, BS, 12V 12AHBATTERY, YTX14, BS, 12V 12AH
-
2602126021-1106 JUNCTION BOXJUNCTION BOX
-
2603026030-1779 HARNESS, FRONTHARNESS, FRONT
-
26030B26030-1959 HARNESS, SUBHARNESS, SUB
-
2603126031-0133 HARNESS, MAINHARNESS, MAIN
-
2700227002-1086 RELAY, ASSYRELAY, ASSY
-
27002A27002-1101 RELAY, ASSY, TURN SIGNALRELAY, ASSY, TURN SIGNAL
-
2700327003-1418 HORN (LEFT)HORN (LEFT)
-
27003A27003-1419 HORN (RIGHT)HORN (RIGHT)
-
4901649016-1177 COVER, SEAL, FUSECOVER, SEAL, FUSE
-
9200992009-1197 SCREW, TAPPING, 5X14SCREW, TAPPING, 5X14
-
9201592015-1367 NUT, FLANGED, 6MMNUT, FLANGED, 6MM
-
9202692026-1575 SPACERSPACER
-
9203792037-1636 CLAMP, HARNESS, L=100CLAMP, HARNESS, L=100
-
9207292072-1195 BAND, L=202BAND, L=202
-
92072A92072-1414 BANDBAND
-
9207592075-1688 DAMPER, JUNCTION BOXDAMPER, JUNCTION BOX
-
9215292152-1252 COLLARCOLLAR
-
9217092170-1494 CLAMP, HARNESSCLAMP, HARNESS
-
9217192171-0375 CLAMP, HARNESSCLAMP, HARNESS
-
92171B92171-1256 CLAMP, HARNESSCLAMP, HARNESS
-
92171C92171-1269 CLAMP, HARNESSCLAMP, HARNESS
-
92171D92171-1371 CLAMP, HARNESSCLAMP, HARNESS
-
92171E92171-1459 CLAMP, HARNESSCLAMP, HARNESS
-
92171F92171-1481 CLAMP, HEAD LAMP COUPLERCLAMP, HEAD LAMP COUPLER
-
130130H0630 BOLT, FLANGED, 6X30BOLT, FLANGED, 6X30
-
130A130J0612 BOLT, FLANGEDBOLT, FLANGED
-
130B130V0610 BOLT, FLANGED, 6X10BOLT, FLANGED, 6X10
-
312312H0600 NUT, HEXNUT, HEX
-
411411E0600 WASHER, PLAIN, 6MMWASHER, PLAIN, 6MM
-
92171G92171-1486 CLAMP, HARNESS AND CABLECLAMP, HARNESS AND CABLE
