FUEL EVAPORATIVE SYSTEM (CALIF ONLY) для Kawasaki NINJA ZX-6R - 2005 года выпуска
-
№АртикулНазвание
-
1101211012-1388 CAP, CANISTER (CALIF. ONLY)CAP, CANISTER (CALIF. ONLY)
-
1105311053-1619 BRACKET (CALIF. ONLY)BRACKET (CALIF. ONLY)
-
11053A11053-1658 BRACKET (CALIF. ONLY)BRACKET (CALIF. ONLY)
-
1616416164-1054 CANISTER (CALIF. ONLY)CANISTER (CALIF. ONLY)
-
1616516165-1001 SEPARATOR (CALIF. ONLY)SEPARATOR (CALIF. ONLY)
-
9201592015-1700 NUT (CALIF. ONLY)NUT (CALIF. ONLY)
-
92015A92015-1757 NUT, WELL, 5MM (CALIF. ONLY)NUT, WELL, 5MM (CALIF. ONLY)
-
9203792037-1104 CLAMP, HOSE (CALIF. ONLY)CLAMP, HOSE (CALIF. ONLY)
-
92037A92037-147 CLAMP, TUBE (CALIF. ONLY)CLAMP, TUBE (CALIF. ONLY)
-
92037B92037-1512 CLAMP, CANISTER (CALIF. ONLY)CLAMP, CANISTER (CALIF. ONLY)
-
92037C92037-1712 CLAMP (CALIF. ONLY)CLAMP (CALIF. ONLY)
-
92037D92037-1903 CLAMP, SPEED, L=80.5 (CALIF. ONLY)CLAMP, SPEED, L=80.5 (CALIF. ONLY)
-
9207292072-1419 BAND, L=50 (CALIF. ONLY)BAND, L=50 (CALIF. ONLY)
-
9215392153-0404 BOLT, SOCKET, 6X16 (CALIF. ONLY)BOLT, SOCKET, 6X16 (CALIF. ONLY)
-
92153A92153-1244 BOLT, SOCKET, 5X16 (CALIF. ONLY)BOLT, SOCKET, 5X16 (CALIF. ONLY)
-
9216192161-0239 DAMPER (CALIF. ONLY)DAMPER (CALIF. ONLY)
-
9219292192-0169 TUBE, CANISTER, FITTING (GREEN) (CALIF. ONLY)TUBE, CANISTER, FITTING (GREEN) (CALIF. ONLY)
-
92192A92192-0170 TUBE, SEPARATOR, CANISTER (BLUE) (CALIF. ONLY)TUBE, SEPARATOR, CANISTER (BLUE) (CALIF. ONLY)
-
92192B92192-0171 TUBE, SEPARATOR, TANK (BLUE) (CALIF. ONLY)TUBE, SEPARATOR, TANK (BLUE) (CALIF. ONLY)
-
92192C92192-0173 TUBE, SEPARATOR, TANK (RED) (CALIF. ONLY)TUBE, SEPARATOR, TANK (RED) (CALIF. ONLY)
-
92192D92192-0175 TUBE, THROTTLE, SEPARATOR (WHITE) (CALIF. ONLY)TUBE, THROTTLE, SEPARATOR (WHITE) (CALIF. ONLY)
-
9221092210-0130 NUT (CALIF. ONLY)NUT (CALIF. ONLY)
-
132132L0614 BOLT, FLANGED, SMALL, M6X14 (CALIF. ONLY)BOLT, FLANGED, SMALL, M6X14 (CALIF. ONLY)
