CLUTCH для Kawasaki Vulcan 2000 Limited - 2006 года выпуска
-
№АртикулНазвание
-
482482J5000 CIRCLIP, TYPE, ECIRCLIP, TYPE, E
-
1308713087-0005 HUB, CLUTCHHUB, CLUTCH
-
1308813088-0001 PLATE, FRICTIONPLATE, FRICTION
-
13088A13088-0011 PLATE, FRICTIONPLATE, FRICTION
-
13088B13088-1146 PLATE, FRICTIONPLATE, FRICTION
-
1308913089-1075 PLATE, CLUTCH, T=2.0PLATE, CLUTCH, T=2.0
-
13089A13089-1080 PLATE, CLUTCH, T=1.6PLATE, CLUTCH, T=1.6
-
13089B13089-1081 PLATE, CLUTCH, T=2.3PLATE, CLUTCH, T=2.3
-
1309113091-1041 HOLDER, CLUTCH SPRINGHOLDER, CLUTCH SPRING
-
1309513095-0001 HOUSING, COMP, CLUTCHHOUSING, COMP, CLUTCH
-
1310613106-0002 SHAFT, CLUTCH RELEASESHAFT, CLUTCH RELEASE
-
1316813168-0006 LEVER, CLUTCHLEVER, CLUTCH
-
1318713187-0002 PLATE, CLUTCH OPERATINGPLATE, CLUTCH OPERATING
-
4610246102-0013 ROD, CLUTCH RELEASEROD, CLUTCH RELEASE
-
9202292022-1390 WASHER, 25.3X44X1WASHER, 25.3X44X1
-
9202692026-0008 SPACER, 30.5X56X2SPACER, 30.5X56X2
-
92026A92026-0009 SPACER, 30.2X64X8.5SPACER, 30.2X64X8.5
-
92026B92026-1238 SPACER, 15X28X1SPACER, 15X28X1
-
9204692046-0001 BEARING, NEEDLE, K40X48X25V3BEARING, NEEDLE, K40X48X25V3
-
92046A92046-1052 BEARING, NEEDLE, AXK1102BEARING, NEEDLE, AXK1102
-
9214592145-0032 SPRING, CLUTCHSPRING, CLUTCH
-
92145A92145-0033 SPRINGSPRING
-
9215092150-1855 BOLT, CLUTCH OPERATINGBOLT, CLUTCH OPERATING
-
9215192151-1749 BOLT, SOCKET, 6X20BOLT, SOCKET, 6X20
-
9215292152-0190 COLLAR, 30X40X52.3COLLAR, 30X40X52.3
-
9220092200-0015 WASHER, 140.1X150X1.2WASHER, 140.1X150X1.2
-
92200A92200-0016 WASHER, 25.5X42X2.6WASHER, 25.5X42X2.6
-
92200B92200-1107 WASHER, 7.7X13X1.0WASHER, 7.7X13X1.0
-
9221092210-0138 NUT, 25MMNUT, 25MM
