FRONT WHEEL для Ktm 625 SMC - 2005 года выпуска
-
№АртикулНазвание
-
158409001644 FRONT WHEEL SP 3,5X17" POL.FRONT WHEEL SP 3,5X17" POL.
-
25480901004491 FRONT HUB CPL. SX SILVERFRONT HUB CPL. SX SILVER
-
354809011000 BEA.SPACERTUBE 35X2 L=79,4BEA.SPACERTUBE 35X2 L=79,4
-
40625069068 GR.BALL BEAR.6906 DDU2CG23S6NMGR.BALL BEAR.6906 DDU2CG23S6NM
-
60760354771 SHAFT SEAL RING 35X47X7 TCSHAFT SEAL RING 35X47X7 TC
-
854809012000 SPACER BUSHING F. FR. WHEELSPACER BUSHING F. FR. WHEEL
-
1050309071175 SPOKE M4,5X175-15G 17" DDESPOKE M4,5X175-15G 17" DDE
-
1150309072000 SPOKE NIPPLE M4,5X0,75 8X21SPOKE NIPPLE M4,5X0,75 8X21
-
1258409070000 RIM FRONT 3,5X17" POLISHEDRIM FRONT 3,5X17" POLISHED
-
1458309073000 RIM BAND 17"RIM BAND 17"
-
2058209060000 BRAKE DISK FRONT D=320MMBRAKE DISK FRONT D=320MM
-
2159009062023 SPECIAL SCREW M6X23 WS=8 10.9SPECIAL SCREW M6X23 WS=8 10.9
-
2258409161000 BRAKE DISC SUPPORTBRAKE DISC SUPPORT
-
2554809081050 PLUG BUSHING WS=27PLUG BUSHING WS=27
-
3058409081000 WHEEL SPINDEL FRO.D=26MMWHEEL SPINDEL FRO.D=26MM
-
3254809082000 SPINDLE SCREW M24X1,5 WS=27SPINDLE SCREW M24X1,5 WS=27
-
506899785 LOCTITE 243 BLUE 6CCMLOCTITE 243 BLUE 6CCM
