BATTERY BOX для Ktm 950 ADVENTURE US - 2005 года выпуска
-
№АртикулНазвание
-
160011058000 STARTER RELAYSTARTER RELAY
-
258011109030 FUSE 30 AFUSE 30 A
-
30015060103 HH COLLAR SCREW M 6X10 WS=8HH COLLAR SCREW M 6X10 WS=8
-
460011059050 BATTERY CABLE L=350MMBATTERY CABLE L=350MM
-
560011097000 GROUND CABLE L=470MMGROUND CABLE L=470MM
-
660011059000 STARTERCABLE L=475MMSTARTERCABLE L=475MM
-
760040009000 RUBBER CAP STARTER PORTRUBBER CAP STARTER PORT
-
860011053000 BATTERY 12V/11AHBATTERY 12V/11AH
-
90014060103 HH COLLAR SCREW M 6X10 WS=8HH COLLAR SCREW M 6X10 WS=8
-
100934060003 HEXAGON NUT DIN0934-M 6HEXAGON NUT DIN0934-M 6
-
1160011062000 BOOSTER CABLE POSITIVEBOOSTER CABLE POSITIVE
-
1260011063000 BOOSTER CABLE NEGATIVEBOOSTER CABLE NEGATIVE
-
130016050121 SCREW FOR PLASTIC D=5X12SCREW FOR PLASTIC D=5X12
-
1458411053050 BATTERY COVER (RUBBER)BATTERY COVER (RUBBER)
-
2060011054007 BATTERY BOX TOP PARTBATTERY BOX TOP PART
-
2160011054000 BATTERY BOXBATTERY BOX
-
2260011054006 BATTERY BOX FRONT PARTBATTERY BOX FRONT PART
-
230017060203 SPECIAL SCREW T60 6X20 WS=6SPECIAL SCREW T60 6X20 WS=6
-
2460011056000 BRACKET STARTER RELAYBRACKET STARTER RELAY
-
2560011055000 BRACKET VOLTAGE REGULATORBRACKET VOLTAGE REGULATOR
-
2660011038000 CAGE NUT M6 SL K100-1 1,5MMCAGE NUT M6 SL K100-1 1,5MM
-
2760038083000 SCREW OIL TANK FIXINGSCREW OIL TANK FIXING
-
2858111076000 CABLE SUPPORT KHS NR.150-47610CABLE SUPPORT KHS NR.150-47610
-
2957013072100 WIRING HOLDER 16MMWIRING HOLDER 16MM
-
3060011034000 VOLTAGE REGULATORVOLTAGE REGULATOR
-
310015060303 HH COLLAR SCREW M 6X30 WS=8HH COLLAR SCREW M 6X30 WS=8
