TRANSMISSION - MAIN SHAFT для Ktm 560 SMR - 2006 года выпуска
-
№АртикулНазвание
-
159033001300 MAIN SHAFT-ZB 16-TMAIN SHAFT-ZB 16-T
-
259033005039 IDLER GEAR 5.G 24-T "39"IDLER GEAR 5.G 24-T "39"
-
30405222613 NEEDLE BEAR. K 22X26X13 TNNEEDLE BEAR. K 22X26X13 TN
-
459033031000 STOP DISC 25,2X32X1,5STOP DISC 25,2X32X1,5
-
559033003046 SLIDING GEAR 3/4.G 20/22-T"46"SLIDING GEAR 3/4.G 20/22-T"46"
-
60471250120 CIRCLIP DIN0471-25X1,2CIRCLIP DIN0471-25X1,2
-
759033030000 STOP DISC 25,2X32X1,5STOP DISC 25,2X32X1,5
-
959033006045 IDLER GEAR 6.G 21-T "45"IDLER GEAR 6.G 21-T "45"
-
1059033002037 SOLID GEAR 2.G 18-T "37"SOLID GEAR 2.G 18-T "37"
-
1156033030000 STOP DISC 17,2X30X1STOP DISC 17,2X30X1
-
120625062034 BALL BEARING 6203 JR C3BALL BEARING 6203 JR C3
-
130625062054 BALL BEARING 6205 C3 NTNBALL BEARING 6205 C3 NTN
Все узлы модели:
- AIR FILTER BOX
- BALANCER SHAFT
- BRAKE CALIPER FRONT
- CARBURETOR
- CLUTCH
- COOLING SYSTEM
- CRANKSHAFT W/ PISTON
- CYLINDER
- CYLINDER HEAD
- DECAL
- ENGINE CASE
- FORK LEGS
- FRAME W/ SUB FRAME
- FRONT WHEEL
- HAND BRAKE CYLINDER
- HANDLEBAR W/ CONTROLS
- IGNITION SYSTEM
- KICKSTARTER
- LUBRICATING SYSTEM
- MANIFOLD
- MASK W/ FENDERS
- REAR BRAKE CALIPER
- REAR BRAKE CONTROL
- REAR WHEEL
- SHIFTING MECHANISM
- SHOCK ABSORBER
- SHOCK ABSORBER - DISASSEMBLED
- SILENCER
- SPECIAL TOOLS
- SWING ARM
- TANK - SEAT - COVER
- TELESCOPIC FORK
- TIMING VALVE
- TRANSMISSION - COUNTER SHAFT
- • TRANSMISSION - MAIN SHAFT
- VALVE DRIVE
