MASK FENDERS для Ktm 990 Superduke Black EU - 2006 года выпуска
-
№АртикулНазвание
-
16100800100030A HEAD LIGHT MASK BLACKHEAD LIGHT MASK BLACK
-
261008005000 MASK BRACKET R/S CPL.MASK BRACKET R/S CPL.
-
361008004000 MASK BRACKET L/S CPL.MASK BRACKET L/S CPL.
-
40017060203 EJOT PT SCREW K60X20EJOT PT SCREW K60X20
-
560013057000 BOLT F. LINK FORK 8X20X16,5BOLT F. LINK FORK 8X20X16,5
-
660013058000 SECURING CLIP D=8MMSECURING CLIP D=8MM
-
758708002000 HINGE JOINT BOTTOMHINGE JOINT BOTTOM
-
831008060000 RUBBER SLEEVE D=8MM OPENRUBBER SLEEVE D=8MM OPEN
-
90015060453 HH COLLAR SCREW M 6X45HH COLLAR SCREW M 6X45
-
1061014070000 INSTRUMENT COVERINSTRUMENT COVER
-
110017050181 SCREW FOR PLASTIC D=5X18SCREW FOR PLASTIC D=5X18
-
120012060123 AH SCREW DIN6912 M6X12AH SCREW DIN6912 M6X12
-
1360008045000 SPECIAL WASHER D=16,5MMSPECIAL WASHER D=16,5MM
-
1461003094000 SPLASH PROTECT. FRAME HEADSPLASH PROTECT. FRAME HEAD
-
1550235033300 SNAP-NUT HOLDER M6 KP142SNAP-NUT HOLDER M6 KP142
-
160014060153 HH COLLAR SCREW M 6X15HH COLLAR SCREW M 6X15
-
20*5870801000033C FENDER FRONT BLACK MATTFENDER FRONT BLACK MATT
-
2150308053000 BUSH FOR SPOILER 6X11X16X7,5BUSH FOR SPOILER 6X11X16X7,5
-
2250308052000 BUSH FOR SPOILER 6X11X16X5 MMBUSH FOR SPOILER 6X11X16X5 MM
-
230015060163 HH COLLAR SCREW M 6X16HH COLLAR SCREW M 6X16
-
2461008019044 REAR END LOWER PART CPL.REAR END LOWER PART CPL.
-
2561008021000 THERMAL PROTECTION FOILTHERMAL PROTECTION FOIL
-
2661008021100 THERMAL PROTECTION FOILTHERMAL PROTECTION FOIL
-
270014060153 HH COLLAR SCREW M 6X15HH COLLAR SCREW M 6X15
-
2861008015000 NUMB.PLATE CARRIERNUMB.PLATE CARRIER
-
3061008014000 SPLASH PROTECT.SPLASH PROTECT.
-
3172210079000 BUCKETBUCKET
-
33*6100804100033B REAR TOPPART L/S BLACK MATREAR TOPPART L/S BLACK MAT
-
34*6100804200033B REAR TOPPART R/S BLACK MATREAR TOPPART R/S BLACK MAT
-
3561008041050 THERMAL PROTECTION FOIL L/STHERMAL PROTECTION FOIL L/S
-
3661008042050 THERMAL PROTECTION FOIL R/STHERMAL PROTECTION FOIL R/S
-
3750308053000 BUSH FOR SPOILER 6X11X16X7,5BUSH FOR SPOILER 6X11X16X7,5
-
390081500181 SCREW FOR PLASTIC D=5X18SCREW FOR PLASTIC D=5X18
-
4061008019050 SPECIAL NUT FOR REAR ENDSPECIAL NUT FOR REAR END
-
4158412080100 REFLECTOR YELLOWREFLECTOR YELLOW
-
5260012081100 LICENCE NUMBER PLATELICENCE NUMBER PLATE
-
530021060003 WASHER DIN9021-A 6,4WASHER DIN9021-A 6,4
-
540985060003 SELF LOCK. NUT DIN0985-M 6SELF LOCK. NUT DIN0985-M 6
-
5558412080000 REFLECTOR RED LC4REFLECTOR RED LC4
-
560966050163 OVAL HEAD SCREW DIN0966-M 5X16OVAL HEAD SCREW DIN0966-M 5X16
-
5740006006000 WASHER 6MMWASHER 6MM
-
5858412080050 BRACKET FOR REFLECTORBRACKET FOR REFLECTOR
-
590125050003 WASHER DIN0125-A 5,3WASHER DIN0125-A 5,3
-
600985050003 SELF LOCKING NUT DIN0985-M 5SELF LOCKING NUT DIN0985-M 5
