DECALS для Polaris XPEDITION 425 (A01CK42AA) (DESERT DUNE) - 2001 года выпуска
-
№АртикулНазвание
-
17170021 DECALDECAL
-
27078018 DECAL, ''4X4'', SHAFT RIDE SYS (LEFT)DECAL, ''4X4'', SHAFT RIDE SYS (LEFT)
-
27078022 DECAL, ''4X4'', SHAFT RIDE SYS (RIGHT)DECAL, ''4X4'', SHAFT RIDE SYS (RIGHT)
-
37078443 DECAL,''POLARIS'' SDPNL (WHITE)DECAL,''POLARIS'' SDPNL (WHITE)
-
47079221 DECAL, TANK SIDE (LEFT)DECAL, TANK SIDE (LEFT)
-
47079222 DECAL, TANK SIDE (RIGHT)DECAL, TANK SIDE (RIGHT)
-
57074935 DECAL 95-97 WARNING AWD SWITCHDECAL 95-97 WARNING AWD SWITCH
-
67078577 DECAL, DRAIN RECOILDECAL, DRAIN RECOIL
-
77078465 DECAL, STAR LOGODECAL, STAR LOGO
-
87078514 DECAL-''425 L/C, 4 STROKE'', FRCVRDECAL-''425 L/C, 4 STROKE'', FRCVR
-
97074220 DECAL, MACPHERSON STRUTDECAL, MACPHERSON STRUT
-
107079083 DECALDECAL
-
117078551 DECAL, 5 SPEEDDECAL, 5 SPEED
-
127079085 DECALDECAL
-
137079108 DECALDECAL
-
147077920 DECAL 98 WARNING PASS. SCRAM.DECAL 98 WARNING PASS. SCRAM.
-
157078253 DECALDECAL
-
167078336 DECAL, REVERSE SWITCHDECAL, REVERSE SWITCH
