AIR BOX ASSY. для Polaris ATP 500 4X4 (A04JD50AA) (CAMO GREEN MET.) (USA) - 2004 года выпуска
-
№АртикулНазвание
-
17517317 SCREWSCREW
-
25432859 DUCT INLETDUCT INLET
-
35411422 GASKET INTAKEGASKET INTAKE
-
45432868 COVER AIRBOXCOVER AIRBOX
-
55811482 SEAL COVERSEAL COVER
-
65811633 FILTER PRECLEAN SLEEVEFILTER PRECLEAN SLEEVE
-
77080595 FILTER AIRFILTER AIR
-
87080413 CLAMP BAND NARROWCLAMP BAND NARROW
-
95432601 COLLAR CARBURETOR INLETCOLLAR CARBURETOR INLET
-
105242044 CLIPCLIP
-
117518306 SCRW HEXAGON WITH TAPERSCRW HEXAGON WITH TAPER
-
127558301 WASHER FLATWASHER FLAT
-
137556091 SPACERSPACER
-
145433678 BOX AIRBOX AIR
-
157080650 CLAMP HOSECLAMP HOSE
-
168450059-150 FUEL LINEFUEL LINE
-
175812111 FOIL (RIGHT)FOIL (RIGHT)
-
185432377 PLUG TRAPPLUG TRAP
-
197080699 CLAMP HOSECLAMP HOSE
-
215830128 GASKET CARBURETOR INLET DUCTGASKET CARBURETOR INLET DUCT
-
225433180 DUCT CARBURETOR INLETDUCT CARBURETOR INLET
-
235412304 BOOT CARBURETORBOOT CARBURETOR
-
247080694 CLAMP HOSE SPRINGCLAMP HOSE SPRING
-
255411921 HOSE BREATHER NITRILEHOSE BREATHER NITRILE
-
262530029 FILTER BREATHER IN LINEFILTER BREATHER IN LINE
-
278450073-600 LINE BREATHER (3/8 ID)LINE BREATHER (3/8 ID)
-
287080499 CLAMP CABLECLAMP CABLE
-
297621432 RIVET (3/16X.402)RIVET (3/16X.402)
