FUEL TANK для Polaris PHOENIX 200 (AVALANCHE GREY) [A18YAP20A8] - 2018 года выпуска
-
№АртикулНазвание
-
10453928 ASM-CAP,FUELASM-CAP,FUEL
-
20453691 CAP-FUEL [INCL. 2,3]CAP-FUEL [INCL. 2,3]
-
30453692 GASKET, CAPGASKET, CAP
-
40455245 TANK-FUEL,PHOENIXTANK-FUEL,PHOENIX
-
40453932 CLIP-AIRBOX,PRED 50CLIP-AIRBOX,PRED 50
-
40455270 FUEL LINE,PHOENIXFUEL LINE,PHOENIX
-
50452216 BOLTBOLT
-
60450676 SCREWSCREW
-
70452913 WASHERWASHER
-
80450632 RUBBER, FUEL TANKRUBBER, FUEL TANK
-
90452645 FOIL, TANKFOIL, TANK
-
100453693 CLAMP, HOSECLAMP, HOSE
-
110455278 ASM-FUEL LINE RES W/CONDUITASM-FUEL LINE RES W/CONDUIT
-
120453623 CLAMP-HOSE,CARBCLAMP-HOSE,CARB
-
130455276 ASM-FUEL LINE W/SLEEVE MAINASM-FUEL LINE W/SLEEVE MAIN
-
140450366 VALVE, FUELVALVE, FUEL
-
150450701 BOLTBOLT
-
160450054 CLIPCLIP
-
170454026 HOSE, FUEL,250 MMHOSE, FUEL,250 MM
-
180453695 FILTER, FUEL, 65 MICRONFILTER, FUEL, 65 MICRON
-
190452646 CLAMPCLAMP
