CRANKCASE для Polaris Virage 3-Pass Euro - 2000 года выпуска
-
№АртикулНазвание
-
12201619 CRANKCASE KIT (INCL. 2 4, 20 22)CRANKCASE KIT (INCL. 2 4, 20 22)
-
25131677 STUD, CYLINDER FLANGE (152MM)STUD, CYLINDER FLANGE (152MM)
-
37663001 PIN, DOWELPIN, DOWEL
-
47052145 FITTINGFITTING
-
55243231 CLAMP, STATOR WIRESCLAMP, STATOR WIRES
-
67517431 SCREWSCREW
-
73569805 BUSHINGBUSHING
-
85433130 PLUG TIMING HOLE (3/4X16)PLUG TIMING HOLE (3/4X16)
-
93574214 BUSHING, PLASTICBUSHING, PLASTIC
-
107041457 SPRINGSPRING
-
113569806 BUSHINGBUSHING
-
127517676 SCREWSCREW
-
137516806 BOLTBOLT
-
141201923 COVER, FLYWHEEL ASSY. (INCL. 11)COVER, FLYWHEEL ASSY. (INCL. 11)
-
155811550 GASKET, FLYWHEEL COVERGASKET, FLYWHEEL COVER
-
167516723 BOLTBOLT
-
177663002 PIN, DOWELPIN, DOWEL
-
185411564 O-RINGO-RING
-
191201938 FLYWHEEL ASSY., HOUSING (INCL. 7, 17)FLYWHEEL ASSY., HOUSING (INCL. 7, 17)
-
207517628 BOLTBOLT
-
217051529 PLUG, BRASS (1/16 PIPE)PLUG, BRASS (1/16 PIPE)
-
227516913 BOLTBOLT
