THROTTLE BODY ASSY. для Polaris Virage i 3-Pass Euro - 2002 года выпуска
![](/wa-data/public/shop/sheme/polaris/pwc/81925073-f73d-41a8-b799-f3e59d44bd28.gif)
-
№АртикулНазвание
-
17516816 SCREWSCREW
-
25631090 BASE INTAKE SILENCER DFIBASE INTAKE SILENCER DFI
-
35830062 GASKET, CARBUREOTR (UPPER)GASKET, CARBUREOTR (UPPER)
-
41253430 THROTTLE BODY ASSY.THROTTLE BODY ASSY.
-
57080571 STRAP, 8 IN. TYTONSTRAP, 8 IN. TYTON
-
67516606 SCREWSCREW
-
75812292 TOP, ELECTRO MOUNTTOP, ELECTRO MOUNT
-
81202208 TPS KIT, ELECTRO OVERMOLDTPS KIT, ELECTRO OVERMOLD
-
95133242 SPACER MOUNTSPACER MOUNT
-
105434359 MOUNTMOUNT
-
117042067 SPRING TORSIONSPRING TORSION
-
125434096 COUPLERCOUPLER
-
137516603 BOLTBOLT
-
142410299 SENSOR AIR TEMP, DFISENSOR AIR TEMP, DFI
