NOSEPAN ASSEMBLY для Polaris 120 XCR (S00WB1AS) - 2000 года выпуска
-
№АртикулНазвание
-
17670102 CLIP, SILENCERCLIP, SILENCER
-
25243896 BRACKET HINGE, NOSEPAN (LEFT)BRACKET HINGE, NOSEPAN (LEFT)
-
25243897 BRACKET HINGE, NOSEPAN (RIGHT)BRACKET HINGE, NOSEPAN (RIGHT)
-
37542122 NUT, LOCKNUT, LOCK
-
47621467 RIVET, BLINDRIVET, BLIND
-
52670134 REFLECTOR ASSY. (AMBER)REFLECTOR ASSY. (AMBER)
-
67512283 SCREW, SEMSSCREW, SEMS
-
77670057 NUT, SPEEDNUT, SPEED
-
81013048-067 CLUTCH COVERCLUTCH COVER
-
97661637 RIVET, INTERLOCK ZRIVET, INTERLOCK Z
-
107078389 DECAL, ENGINE AND CLUTCHDECAL, ENGINE AND CLUTCH
-
115433526-293 NOSEPAN, XJR (RED)NOSEPAN, XJR (RED)
-
125244079 BRACE, BUMPER (FRONT/LEFT)BRACE, BUMPER (FRONT/LEFT)
-
125244080 BRACE, BUMPER (FRONT/RIGHT)BRACE, BUMPER (FRONT/RIGHT)
-
137515166 SCREWSCREW
-
145433536-070 BUMPER (FRONT/BLACK)BUMPER (FRONT/BLACK)
Все узлы модели:
- BLOWER HOUSING W/ RECOIL STARTER ASSEMBLY
- CAMSHAFT W/ VALVE ASSY. AND AIR CLEANER
- CARBURETOR ASSEMBLY
- CLUTCH ASSEMBLY
- CONSOLE W/WIRE HARNESS
- CRANKCASE ASSEMBLY
- DECALS
- DRIVE TRAIN ASSEMBLY W/ TRACK
- ELECTRICAL - MAGNETO ASSEMBLY W/ COIL
- ENGINE MOUNTING W/ SHORT BLOCK
- HANDLEBAR ASSEMBLY W/ CONTROLS
- HOOD ASSEMBLY W/ WINDSHIELD
- • NOSEPAN ASSEMBLY
- PISTON AND CRANKSHAFT
- SEAT W/ GAS TANK ASSEMBLY
- SKI ASSEMBLY
- SPEED CONTROL - GOVERNER
- SUSPENSION - FRONT W/ STEERING
- SUSPENSION - REAR
- TOOL KIT
- TUNNEL ASSEMBLY
