SPEED CONTROL - GOVERNER для Polaris 120 XCR (S00WB1AS) - 2000 года выпуска
-
№АртикулНазвание
-
13084566 BOLT, FLANGEBOLT, FLANGE
-
23086605 PLATE, STOPPLATE, STOP
-
33086954 WASHER, FRICTIONWASHER, FRICTION
-
43086609 SCREWSCREW
-
53086606 SPRING, IDLE SETSPRING, IDLE SET
-
63086604 KNOB, CONTROL, SPEEDKNOB, CONTROL, SPEED
-
73081497 SCREWSCREW
-
83083073 NUTNUT
-
93081600 SCREW AND WASHERSCREW AND WASHER
-
107556129 RET.RING 1200-18 STPARET.RING 1200-18 STPA
-
113086973 BRACKET, WIREBRACKET, WIRE
-
123086125 BOLT, FLANGEBOLT, FLANGE
-
133086862 BRACKET, RETURN SPRINGBRACKET, RETURN SPRING
-
143086956 SPRING, RETURNSPRING, RETURN
-
153086599 SPRING, GOVERNORSPRING, GOVERNOR
-
163086597 SPRING, RODSPRING, ROD
-
173086596 ROD, GOVERNORROD, GOVERNOR
-
183086594 LEVER, GOVERNORLEVER, GOVERNOR
-
193086598 NUTNUT
-
203082038 BOLT AND WASHER ASSY.BOLT AND WASHER ASSY.
-
213086053 CLIPCLIP
-
223086595 SHAFT, GOVERNORSHAFT, GOVERNOR
-
233086955 SPACERSPACER
-
243086944 SPEED CONTROL, ASSY. (INCL. 6)SPEED CONTROL, ASSY. (INCL. 6)
