CLUTCH - DRIVEN для Polaris 500 INDY (S00SB4BS) - 2000 года выпуска
-
№АртикулНазвание
-
17512048 SCREWSCREW
-
25210749 PLATEPLATE
-
37714804 RING, RETAININGRING, RETAINING
-
47556804 WASHERWASHER
-
55130895 RAMP, DRIVEN (36 DEGREE)RAMP, DRIVEN (36 DEGREE)
-
67721103 KEY SQUAREKEY SQUARE
-
77041501 SPRING, CLUTCH (GOLD)SPRING, CLUTCH (GOLD)
-
83569803 BUSHING, D.U.BUSHING, D.U.
-
97555898 WASHER (.02)WASHER (.02)
-
97556076 WASHER (.025)WASHER (.025)
-
97556804 WASHER (.03)WASHER (.03)
-
107555865 WASHER, DRIVE CLUTCHWASHER, DRIVE CLUTCH
-
115020653 PIN, CLUTCHPIN, CLUTCH
-
125222878 CAM, DRIVEN, ADJUSTABLECAM, DRIVEN, ADJUSTABLE
-
137515133 SCREWSCREW
-
145230101 CAP DRIVENCAP DRIVEN
-
155430466 BUTTON, RAMPBUTTON, RAMP
-
161322199 CLUTCH, DRIVEN (36 DEGREE) (GOLD) (INCL. 1, 15)CLUTCH, DRIVEN (36 DEGREE) (GOLD) (INCL. 1, 15)
Все узлы модели:
- BRAKE ASSEMBLY
- CARBURETOR ASSEMBLY
- CHAINCASE ASSEMBLY
- CLUTCH - DRIVE
- • CLUTCH - DRIVEN
- CONSOLE
- COOLING SYSTEM
- CRANKCASE ASSEMBLY
- CYLINDER ASSEMBLY
- DECALS
- DRIVE TRAIN ASSEMBLY W/ DRIVE BELT
- ELECTRICAL - MAGNETO ASSEMBLY W/ COIL
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL PUMP
- HANDLEBAR ASSEMBLY
- HOOD - FOAM/FOIL
- HOOD ASSEMBLY W/ HEADLIGHT
- HOOD ASSEMBLY W/ WINDSHIELD
- NOSEPAN ASSEMBLY #1
- NOSEPAN ASSEMBLY #2
- OIL PUMP ASSEMBLY
- OIL TANK W/ AIR BOX ASSEMBLY
- PISTON AND CRANKSHAFT
- RAIL ASSEMBLY W/ IDLER WHEELS
- SEAT W/ GAS TANK ASSEMBLY
- STARTER - RECOIL ASSEMBLY
- STEERING ASSEMBLY
- SUSPENSION - FRONT TORQUE ARM ASSEMBLY
- SUSPENSION - FRONT W/ SKI
- SUSPENSION - RAIL MOUNTING
- SUSPENSION - REAR TORQUE ARM ASSEMBLY
- TOOL KIT
- TUNNEL ASSEMBLY
- WATER PUMP
