RAIL ASSEMBLY W/ IDLER WHEELS #1 для Polaris 600 TOURING (S00ST6ES) - 2000 года выпуска
-
№АртикулНазвание
-
17515526 BOLTBOLT
-
27552603 WASHERWASHER
-
37710439 RING, RETAININGRING, RETAINING
-
41594067 WHEEL, BOGIEWHEEL, BOGIE
-
51541025-067 TENSIONER, SHAFT (BLK)TENSIONER, SHAFT (BLK)
-
67517247 SCREWSCREW
-
77542411 NUT LOCKNUT LOCK
-
87555893 WASHERWASHER
-
97555806 WASHERWASHER
-
107571629 WASHERWASHER
-
111594083-256 WHEEL, IDLER, SCRL (C.RED)WHEEL, IDLER, SCRL (C.RED)
-
125432535 SPACER, IDLERSPACER, IDLER
-
137555918 BUSHINGBUSHING
-
141594087 WHEEL ASSY, PLAIN (6.38 O.D.)WHEEL ASSY, PLAIN (6.38 O.D.)
-
155333285 SPACER, IDLER, LONGSPACER, IDLER, LONG
-
165020744 SHAFT, IDLERSHAFT, IDLER
-
177517353 SCREWSCREW
-
187556301 MACHINERY BUSHINGMACHINERY BUSHING
-
195332784 SPACER (OUTER)SPACER (OUTER)
-
205020415 SHAFT, PIVOT ARMSHAFT, PIVOT ARM
-
225332783 TUBE, SUSPENSIONTUBE, SUSPENSION
-
235131112 BOSS, BOLT HEADBOSS, BOLT HEAD
-
247517380 SCREWSCREW
-
255241473 CLIP, SLIDECLIP, SLIDE
-
255241474 CLIP, GUIDECLIP, GUIDE
-
255411687 TRACK, LIGHTNING (133''X.82)TRACK, LIGHTNING (133''X.82)
-
267080424 FITTING, LUBE.FITTING, LUBE.
-
271012267-067 SHAFT, LIMITER STRAP (BLK)SHAFT, LIMITER STRAP (BLK)
-
281540968-067 ARM, SHOCK PIVOTARM, SHOCK PIVOT
-
295333404 SHAFTSHAFT
-
305020649 SHAFT, SHOCK BRACKET (REAR)SHAFT, SHOCK BRACKET (REAR)
-
311541141-067 ARM, PIVOT (X12) (BLK) (REAR)ARM, PIVOT (X12) (BLK) (REAR)
