SUSPENSION - FRONT для Polaris 600 TOURING (S00ST6ES) - 2000 года выпуска
-
№АртикулНазвание
-
17661638 RIVET, INTERLOCK BRIVET, INTERLOCK B
-
21012575-067 BRACE, BULKHEAD (FRONT) (BLK)BRACE, BULKHEAD (FRONT) (BLK)
-
35211345 STRAP, SPACER (BOTTOM)STRAP, SPACER (BOTTOM)
-
47558702 WASHER THRUSTWASHER THRUST
-
57512551 BOLTBOLT
-
67542703 NUT FLEXNUT FLEX
-
77515415 BOLTBOLT
-
87542439 NUT, NYLOKNUT, NYLOK
-
97041795 SHOCK, GAS, SELECT (IFS)SHOCK, GAS, SELECT (IFS)
-
105630580 RETAINER, SPRING, SLOTTEDRETAINER, SPRING, SLOTTED
-
117041551-067 SPRING, COMPRESSIONSPRING, COMPRESSION
-
125431734 RING, SPRING PRELOAD ADJUSTRING, SPRING PRELOAD ADJUST
-
131500063 RETAINER, SPRING, BODY, THREADEDRETAINER, SPRING, BODY, THREADED
-
145243438-067 TORSION, BAR (X-12)TORSION, BAR (X-12)
-
155432038 BUSHING, SWAY BARBUSHING, SWAY BAR
-
167621477 RIVETRIVET
-
175241660-067 ARM, STEERING (BLK) (LEFT)ARM, STEERING (BLK) (LEFT)
-
175241661-067 ARM, STEERING (BLK) (RIGHT)ARM, STEERING (BLK) (RIGHT)
-
187515433 BOLTBOLT
-
197517583 SCREWSCREW
-
207555832 WASHERWASHER
-
217542403 NUT LOCKNUT LOCK
-
227661643 RIVET (-3/16-.214-.420)RIVET (-3/16-.214-.420)
-
237555721 WASHERWASHER
-
245010310 TUBE, BUSHINGTUBE, BUSHING
-
255410872 PIVOT, TRAILING ARM, RUBBERPIVOT, TRAILING ARM, RUBBER
-
267512557 BOLTBOLT
-
271822517 TRAILING, ARM KIT (LEFT) (INCL. 24, 25)TRAILING, ARM KIT (LEFT) (INCL. 24, 25)
-
271822518 TRAILING, ARM KIT (RIGHT) (INCL. 24, 25)TRAILING, ARM KIT (RIGHT) (INCL. 24, 25)
-
285432561 SLIDE, SWAYBAR (5/8)SLIDE, SWAYBAR (5/8)
-
295241777-067 STOP, STEERING (BLK) (LEFT)STOP, STEERING (BLK) (LEFT)
-
295241778-067 STOP, STEERING (BLK) (RIGHT)STOP, STEERING (BLK) (RIGHT)
-
303573909 BUSHING, FLANGEBUSHING, FLANGE
-
317556509 WASHER SPECIALWASHER SPECIAL
-
323574208 BUSHING, SPINDLE HOUSINGBUSHING, SPINDLE HOUSING
-
337080306 FITTING, LUBE.W/BALL CHECKFITTING, LUBE.W/BALL CHECK
-
346230102-067 SHAFT, SPINDLE, TRAILING (BLK)SHAFT, SPINDLE, TRAILING (BLK)
-
355010158 BUSHING, PIVOTBUSHING, PIVOT
-
367080433 ZERK, FITTING, THREADEDZERK, FITTING, THREADED
-
375431486 BUSH, RADIUS ROD PIVOT (OUTER)BUSH, RADIUS ROD PIVOT (OUTER)
-
385010127 BUSHING, RADIUS RODBUSHING, RADIUS ROD
-
391820673-067 RADIUS ROD (LOWER) (BLK)RADIUS ROD (LOWER) (BLK)
-
407542711 NUT, JAMNUT, JAM
-
417061027 ROD, END RADIUS (RIGHT) (LOWER0ROD, END RADIUS (RIGHT) (LOWER0
-
425242578 BRACKET, RADIUS ROD (BOTTOM)BRACKET, RADIUS ROD (BOTTOM)
-
447512684 BOLTBOLT
-
457542503 NUT, LOCKNUT, LOCK
-
467061010 ROD, END (7/16 LINED)ROD, END (7/16 LINED)
-
477542520 NUT JAMNUT JAM
-
481820672-067 RADIUS ROD (UPPER) (BLK)RADIUS ROD (UPPER) (BLK)
