REVERSE LINKAGE для Polaris EURO WIDETRAK LX (E01SU4BU) - 2000 года выпуска
-
№АртикулНазвание
-
15432960 LEVER, SHIFTLEVER, SHIFT
-
27661843 CLEVISCLEVIS
-
31341292 ACTUATORACTUATOR
-
47556060 WASHER, WAVEWASHER, WAVE
-
57517607 BOLT, SHOULDERBOLT, SHOULDER
-
67542101 NUT HEX, LOCKNUT HEX, LOCK
-
77517386 SCREWSCREW
-
85132063 ROD, THREADEDROD, THREADED
-
97542129 NUTNUT
-
107061029 ROD ENDROD END
-
117515159 SCREWSCREW
-
127547088 NUT, JAM (LEFT)NUT, JAM (LEFT)
-
137061039 ROD, END (1/4, 28X.375) (LEFT)ROD, END (1/4, 28X.375) (LEFT)
-
147515102 SCREWSCREW
-
157555806 WASHERWASHER
-
167542402 NUT, FLEX LOCNUT, FLEX LOC
-
175242787 BRACKET, SHIFT ACTUATOR SETBRACKET, SHIFT ACTUATOR SET
-
187661010 PIN, COTTERPIN, COTTER
