SKI ASSEMBLY для Polaris WIDETRAK LX (S03SU4BS) - 2003 года выпуска
-
№АртикулНазвание
-
17542321 NUT, FLANGENUT, FLANGE
-
25434165-070 TOE PLASTIC SKI (BLACK)TOE PLASTIC SKI (BLACK)
-
37542439 NUT, NYLOKNUT, NYLOK
-
47555832 WASHERWASHER
-
57661209 PIN-COTTERPIN-COTTER
-
67542438 NUT, CASTLENUT, CASTLE
-
77556130 WASHER .406X1.25X.125WASHER .406X1.25X.125
-
85132637 BUSHING, METAL, .390 IDBUSHING, METAL, .390 ID
-
95412018 STOP, RUBBERSTOP, RUBBER
-
107542324 NUT, NYLOKNUT, NYLOK
-
117555843 WASHER, WROUGHTWASHER, WROUGHT
-
121821337-070 SKI ASSY., LEFT WIDE, SVC (BLACK) (INCL. 8)SKI ASSY., LEFT WIDE, SVC (BLACK) (INCL. 8)
-
121821338-070 SKI ASSY., RIGHT WIDE, SVC (BLACK) (INCL. 8)SKI ASSY., RIGHT WIDE, SVC (BLACK) (INCL. 8)
-
137515462 SCREWSCREW
-
142874334 SKAG KIT, CARBIDE, 4", 60ШSKAG KIT, CARBIDE, 4", 60Ш
-
157515514 BOLTBOLT
-
167518070 SCR 5/16 18X1, TRX, GR5, YSCR 5/16 18X1, TRX, GR5, Y
