EXHAUST SYSTEM для Polaris 120 DRAGON (BLACK) (S08WB1AEA) - 2008 года выпуска
-
№АртикулНазвание
-
13086570 BOLT, PIVOTBOLT, PIVOT
-
23087013 ARM-ROCKERARM-ROCKER
-
33086568 ROD, PUSHROD, PUSH
-
43086565 VALVE, INTAKEVALVE, INTAKE
-
53086566 VALVE, EXHAUSTVALVE, EXHAUST
-
63084912 NUTNUT
-
77556144 WSHR, FIBER .76X.25X.093WSHR, FIBER .76X.25X.093
-
87542103 NUT, FLEXLOCNUT, FLEXLOC
-
93110050 MOUNT, CARBURETORMOUNT, CARBURETOR
-
107558301 WASHER, FLATWASHER, FLAT
-
117542101 NUT HEX-LOCKNUT HEX-LOCK
-
123086562 TAPPETTAPPET
-
133086986 SPRING-RETURNSPRING-RETURN
-
143086987 PIN-SPRINGPIN-SPRING
-
153086557 LEVER, RELEASELEVER, RELEASE
-
163086559 RING, SNAPRING, SNAP
-
173086558 PIN, SPRINGPIN, SPRING
-
183086554 CAMSHAFT (INCL. 15, 16, 17)CAMSHAFT (INCL. 15, 16, 17)
-
193089423 MUFFLERMUFFLER
-
207552901 WASHER, SPRING LOCKWASHER, SPRING LOCK
-
217542301 NUT HEXNUT HEX
-
227555954 WASHERWASHER
-
233086574 GASKET, EXHAUSTGASKET, EXHAUST
-
247512310 SCREWSCREW
-
251261014-029 HEADPIPE, BLACKHEADPIPE, BLACK
-
263086575 NUTNUT
-
273086571 PLATE, GUIDEPLATE, GUIDE
-
283086563 SPRING, VALVESPRING, VALVE
-
293088206 RETAINER-SPRINGRETAINER-SPRING
-
303086567 VALVE, COLLETVALVE, COLLET
