SUSPENSION - REAR для Polaris 120 DRAGON (BLACK) (S08WB1AEA) - 2008 года выпуска
-
№АртикулНазвание
-
15333826 SPACER-CARRIER WHEELSPACER-CARRIER WHEEL
-
21541403 WHEEL-CARRIER (INCL. 4, 5)WHEEL-CARRIER (INCL. 4, 5)
-
35132254 SHAFT-CARRIERSHAFT-CARRIER
-
47710444 RING, RETAININGRING, RETAINING
-
53514384 BEARING-.7874X1.6535X.4724, NTNBEARING-.7874X1.6535X.4724, NTN
-
65811954 STRAP-LIMITER, REARSTRAP-LIMITER, REAR
-
77517846 SCR-5/16-18X3/4, HX/FL, GR5-Y, 80SCR-5/16-18X3/4, HX/FL, GR5-Y, 80
-
87512307 SCREWSCREW
-
97555960 WASHER, FLATWASHER, FLAT
-
107542344 NUT, NYLOKNUT, NYLOK
-
117555734 WASHER, FLATWASHER, FLAT
-
127517227 SCREWSCREW
-
137556171 WASHER-DISH, LK(4818-14-01)-ZWASHER-DISH, LK(4818-14-01)-Z
-
145132253 SHAFT-IDLER, REARSHAFT-IDLER, REAR
-
157621512 RIVETRIVET
-
165241628 BRKT, IDLER, ADJBRKT, IDLER, ADJ
-
177542451 NUT, NYLOKNUT, NYLOK
-
181541415 RAIL, XTRA LITE 68'', LEFT HAND, ASM.RAIL, XTRA LITE 68'', LEFT HAND, ASM.
-
181541416 RAIL, XTRA LITE 68'', RIGHT HAND, ASM.RAIL, XTRA LITE 68'', RIGHT HAND, ASM.
-
195333932 SPACER-IDLER 1 1/8 OD X.834 IDSPACER-IDLER 1 1/8 OD X.834 ID
-
201590279-544 ASM-WHL SCRLLED, 5.35, 20MM PINK (INCL. 4, 5)ASM-WHL SCRLLED, 5.35, 20MM PINK (INCL. 4, 5)
-
217556130 WASHER-.406X1.25X.125WASHER-.406X1.25X.125
-
227512492 SCREWSCREW
-
237515385 SCREWSCREW
-
245434124-070 BLOCK-TOE STOP, BLACKBLOCK-TOE STOP, BLACK
-
257515317 BOLTBOLT
-
267552901 WASHER, SPRING LOCKWASHER, SPRING LOCK
-
277670068 NUT, PUSH-ONNUT, PUSH-ON
-
285521557-309 HI-FAX, NATURALHI-FAX, NATURAL
-
295521499 BUMPER, JOUNCE FRONTBUMPER, JOUNCE FRONT
-
307515199 SCREWSCREW
-
317661621 PIN-HOOD HINGEPIN-HOOD HINGE
-
325132711 SHAFT-LOWER TORQUE ARMSHAFT-LOWER TORQUE ARM
-
335811953 STRAP-LIMITER, FRONTSTRAP-LIMITER, FRONT
-
345132257 SHAFT-UPPER TORQUE ARMSHAFT-UPPER TORQUE ARM
-
357041844-067 SPRING-TORSION, LEFT HAND, BLACKSPRING-TORSION, LEFT HAND, BLACK
-
357041845-067 SPRING-TORSION, RIGHT HAND, BLACKSPRING-TORSION, RIGHT HAND, BLACK
-
365433507 SLEEVE-TORSION SPRINGSLEEVE-TORSION SPRING
-
371541398-067 TORQUE ARM, BLACKTORQUE ARM, BLACK
-
387080424 FITTING, LUBRICATIONFITTING, LUBRICATION
