STEERING - LOWER W/TIE RODS для Polaris 700 RMK 155 AND ES - 2009 года выпуска
-
№АртикулНазвание
-
17061164 ROD END-3/8,PL,75°,1.00, RIGHT HANDROD END-3/8,PL,75°,1.00, RIGHT HAND
-
27542401 NUT,HEX, RIGHT HANDNUT,HEX, RIGHT HAND
-
35334666 ROD-TIEROD-TIE
-
47542424 NUT, LEFT HANDNUT, LEFT HAND
-
57547263 NUT-3/8-24 NYLOKNUT-3/8-24 NYLOK
-
67518277 SCR-3/8-16X3.25 FLG HG5 ZSCR-3/8-16X3.25 FLG HG5 Z
-
77518372 SCR-3/8-24X1.25 TX/TRUSS,GR5-YSCR-3/8-24X1.25 TX/TRUSS,GR5-Y
-
87515545 BOLTBOLT
-
91822907 ASM-DRAGLINK,15.31, FIXEDASM-DRAGLINK,15.31, FIXED
-
101821419 ASM.,ARM-IDLERASM.,ARM-IDLER
-
117061163 ROD END-3/8,PL,75° LEFT HAND,750 STUDROD END-3/8,PL,75° LEFT HAND,750 STUD
-
127555806 WASHER,FLATWASHER,FLAT
-
137547180 NUT-FLANGED,3/8-16 NYLON-ZNUT-FLANGED,3/8-16 NYLON-Z
-
145135452 SPACER-TUBE PITMAN/IDLER ARMSSPACER-TUBE PITMAN/IDLER ARMS
-
151822908 ASM-PITMAN ARM (INCL 17-19)ASM-PITMAN ARM (INCL 17-19)
-
167061152 LINK-FIXED,9.30LINK-FIXED,9.30
-
175132106 BUSHING-REDUCER,12MM TO .385BUSHING-REDUCER,12MM TO .385
-
183514320 BEARING-BALL, 600ILLUBEARING-BALL, 600ILLU
-
195436574 COVER-TIE ROD BOOT, LEFT HANDCOVER-TIE ROD BOOT, LEFT HAND
-
195436575 COVER-TIE ROD BOOT, RIGHT HANDCOVER-TIE ROD BOOT, RIGHT HAND
-
207512084 SCREWSCREW
-
215413631 BOOT-TIE ROD, LEFT HANDBOOT-TIE ROD, LEFT HAND
-
215413632 BOOT-TIE ROD, RIGHT HANDBOOT-TIE ROD, RIGHT HAND
-
227080761 CABLE TIE,14''CABLE TIE,14''
-
237556242 WASHER-.385X.88X.075,FL-Y THRWASHER-.385X.88X.075,FL-Y THR
-
247670125 FASTNER-PUSH-ON CLIP,.250FASTNER-PUSH-ON CLIP,.250
