OIL PUMP для Polaris RANGER TM [A05RB63AA] - 2005 года выпуска
-
№АртикулНазвание
-
13087117 BOLT-FLANGEBOLT-FLANGE
-
23089557 ASM.,FUEL PIPEASM.,FUEL PIPE
-
33088462 CLAMP-HOSECLAMP-HOSE
-
43089558 HOSEHOSE
-
53087256 BOLT,FLANGEBOLT,FLANGE
-
63083391 ASM.,CLAMPASM.,CLAMP
-
73088797 PIPE,RUBBERPIPE,RUBBER
-
83088447 ROTOR-INNERROTOR-INNER
-
93088739 SEAL,OILSEAL,OIL
-
103088792 ASM,OIL PUMP COVERASM,OIL PUMP COVER
-
113088791 BOLT,FLANGEBOLT,FLANGE
-
123088448 ROTOR-OUTERROTOR-OUTER
-
133088793 O-RINGO-RING
-
143088311 ASM-OIL FILTERASM-OIL FILTER
-
153088230 BALL-STEELBALL-STEEL
-
163089756 SPRING-RELIEF VALVESPRING-RELIEF VALVE
-
173082717 GASKET-ALUMGASKET-ALUM
-
183088452 PLUG-OIL RELIEFPLUG-OIL RELIEF
-
193088451 PUMP-OIL FILTER UNITPUMP-OIL FILTER UNIT
-
203088455 BOLT-FLANGEBOLT-FLANGE
-
213088446 GAUGE-OIL,COMPL.GAUGE-OIL,COMPL.
-
223088794 ASM,OIL FILLER CAPASM,OIL FILLER CAP
-
233088457 GASKET-CARBURETORGASKET-CARBURETOR
Все узлы модели:
- BOX - FRAME
- BOX ASSY.
- BOX MOUNTING
- BRAKE - FRONT CALIPER
- BRAKE - MASTER CYLINDER W/ BRAKE LINE
- BRAKE - REAR CALIPERS
- BRAKE - REAR W/ FOOT PEDAL
- CAMSHAFT W/ VALVE ASSY.
- CARBURETOR
- CLUTCH - DRIVE
- CLUTCH - DRIVEN
- CRANKCASE
- CRANKSHAFT W/ PISTON
- DASH INSTRUMENTS W/ CONTROLS
- DECALS
- DRIVESHAFT - REAR
- ELECTRICAL W/ BATTERY
- EXHAUST SYSTEM
- FAN W/ SHROUD
- FRAME W/ EXTENTIONS
- FUEL PUMP
- FUEL TANK
- GEAR SELECTOR W/ DIFFERENTIAL LOCK
- GEARCASE
- GEARCASE - REAR
- GOVERNOR
- HOOD
- MAGNETO - STARTER - RELAYS
- MOLDINGS
- MOUNTING - ENGINE
- MOUNTING - TRANSMISSION
- • OIL PUMP
- PARK BRAKE PEDAL
- PARK BRAKE W/ LOCK CABLES
- SEAT ASSY.
- STARTING MOTOR
- STEERING POST
- SUSPENSION - FRONT A - ARM W/ TIE RODS
- SUSPENSION - FRONT STRUT
- SUSPENSION - REAR SHOCK
- SUSPENSION - SWING ARM W/ REAR SHOCK ASSY
- TAILGATE
- THROTTLE
- TOOL KIT
- WHEEL - FRONT
- WHEEL - REAR
