BRAKE - FRONT CALIPER для Suzuki RM85L8 - 2018 года выпуска
-
№АртикулНазвание
-
159300-03B30-999 CALIPER ASSY, FRONT (LH)CALIPER ASSY, FRONT (LH)
-
259301-03810 ...PISTON SET...PISTON SET
-
359300-40810 ......SEAL SET, PISTON......SEAL SET, PISTON
-
459315-20E00 ...SPRING, PAD...SPRING, PAD
-
559312-36500 ...BOOT, AXLE...BOOT, AXLE
-
659313-36500 ...INSULATOR, AXLE...INSULATOR, AXLE
-
769141-03B00 ...PIN, PAD...PIN, PAD
-
869142-45000 ...CLIP, PAD PIN...CLIP, PAD PIN
-
959121-03B00 ...BLEEDER...BLEEDER
-
1059122-02B40 ...CAP, BLEEDER...CAP, BLEEDER
-
1159116-20E00 ...GUIDE...GUIDE
-
1259350-03B00 ...CARRIER, CALIPER, (LH)...CARRIER, CALIPER, (LH)
-
1359301-03820 PAD & SHIM SETPAD & SHIM SET
-
1459371-03B00 ...SHIM...SHIM
-
1509103-08377 BOLT (8X32)BOLT (8X32)
