ELECTRICAL - WIRING HARNESS (CANADA) для Suzuki VZ800C L2 - 2012 года выпуска
-
№АртикулНазвание
-
136610-41FQ0 HARNSSS, WIRING (INCL. 2-7)HARNSSS, WIRING (INCL. 2-7)
-
232800-16A00 RECTIFIER ASSYRECTIFIER ASSY
-
336717-41F00 BOOTBOOT
-
409481-10501 FUSE (10A)FUSE (10A)
-
509481-20501 FUSE (20A)FUSE (20A)
-
609407-05410 CLAMPCLAMP
-
709407-17403 CLAMP (L:154)CLAMP (L:154)
-
836611-16G00 TAPE, HARNESS (28X50)TAPE, HARNESS (28X50)
-
936611-41F00 TAPE, HARNESS (35X35)TAPE, HARNESS (35X35)
-
1036856-41F00 WIRE, REAR COMB NO.2WIRE, REAR COMB NO.2
-
1136858-41F00 WIRE, REAR COMBWIRE, REAR COMB
-
1236920-33C00 PROTECTOR, WIRING HANRESSPROTECTOR, WIRING HANRESS
-
1336920-45G00 PROTECTOR, WIRING HARNESSPROTECTOR, WIRING HARNESS
-
1494474-17H00 PROTECTOR, WIRING HARNESSPROTECTOR, WIRING HARNESS
-
1509404-06433 CLAMP (L:95)CLAMP (L:95)
-
1609404-06435 CLAMP (L:135)CLAMP (L:135)
-
1709407-14407 CLAMP (L:145)CLAMP (L:145)
-
1809407-18402 CLAMP (L:165)CLAMP (L:165)
-
1909407-19401 CLAMP (L:190)CLAMP (L:190)
-
2037102-41870 LOCK SET (INCL. 21)LOCK SET (INCL. 21)
-
2137100-41F70 LOCK ASSY, STEERINGLOCK ASSY, STEERING
-
2209139-08016 BOLT (8X20)BOLT (8X20)
-
2337187-41F10 PROTECTOR, IGNITION SWITCHPROTECTOR, IGNITION SWITCH
-
2437740-24A00 SWITCH ASSY, STOP LAMPSWITCH ASSY, STOP LAMP
-
2509443-06073 SPRINGSPRING
-
2637840-41F00 SWITCH ASSY, SIDE STANDSWITCH ASSY, SIDE STAND
-
2709103-06279 BOLT (6X20)BOLT (6X20)
-
2838500-41F30 HORN ASSYHORN ASSY
-
2901550-0816A BOLTBOLT
-
3038740-24A00 RELAY ASSY, HEAD LAMPRELAY ASSY, HEAD LAMP
-
3138740-24X50 RELAY ASSY, FUEL PUMPRELAY ASSY, FUEL PUMP
-
3237146-41FA0 KEY, BLANKKEY, BLANK
