INTAKE PIPE W/ COVER (CANADA ONLY) для Suzuki GSX-R1000 L3 - 2013 года выпуска
-
№АртикулНазвание
-
194420-47H00 PIPE, AIR INTAKE RIGHTPIPE, AIR INTAKE RIGHT
-
294430-47H00 PIPE, AIR INTAKE LEFTPIPE, AIR INTAKE LEFT
-
394423-47H00 MOLDING, RIGHTMOLDING, RIGHT
-
494433-47H00 MOLDING, LEFTMOLDING, LEFT
-
509409-06314-5PK CLIP (BLACK)CLIP (BLACK)
-
609148-05052 NUTNUT
-
709320-08028 CUSHIONCUSHION
-
801550-0616A BOLTBOLT
-
909169-06082 WASHERWASHER
-
1094671-47H10-YUA COVER, INTAKE FRONT (YUA - BLUE FOR GLR)COVER, INTAKE FRONT (YUA - BLUE FOR GLR)
-
1094671-47H10-YMC COVER, INTAKE FRONT (YMC - SILVER FOR KGL)COVER, INTAKE FRONT (YMC - SILVER FOR KGL)
-
1194672-47H10-YBD COVER, INTAKE RIGHT (YBD - WHITE FOR GLR)COVER, INTAKE RIGHT (YBD - WHITE FOR GLR)
-
1194672-47H10-YKV COVER, INTAKE RIGHT (YKV - BLACK FOR KGL)COVER, INTAKE RIGHT (YKV - BLACK FOR KGL)
-
1294682-47H10-YBD COVER, INTAKE LEFT (YBD - WHITE FOR GLR)COVER, INTAKE LEFT (YBD - WHITE FOR GLR)
-
1294682-47H10-YKV COVER, INTAKE LEFT (YKV - BLACK FOR KGL)COVER, INTAKE LEFT (YKV - BLACK FOR KGL)
-
1394443-06G00 TAPETAPE
-
1433652-29F00 CUSHIONCUSHION
-
1594479-35F00 CLIPCLIP
-
1694473-47H00-YUA COWL, SIDE UPPER RIGHT (YUA - BLUE FOR GLR)COWL, SIDE UPPER RIGHT (YUA - BLUE FOR GLR)
-
1694473-47H00-YVB COWL, SIDE UPPER RIGHT (YVB - BLACK FOR KGL)COWL, SIDE UPPER RIGHT (YVB - BLACK FOR KGL)
-
1794483-47H00-YUA COWL, SIDE UPPER LEFT (YUA - BLUE FOR GLR)COWL, SIDE UPPER LEFT (YUA - BLUE FOR GLR)
-
1794483-47H00-YVB COWL, SIDE UPPER LEFT (YVB - BLACK FOR KGL)COWL, SIDE UPPER LEFT (YVB - BLACK FOR KGL)
-
1809139-05077 SCREW (5X16)SCREW (5X16)
-
1903541-0516A SCREWSCREW
-
2009132-05050 SCREW (5X12)SCREW (5X12)
