BRAKE PEDAL для Suzuki VL800 L4 B.O.S.S. - 2014 года выпуска
-
№АртикулНазвание
-
142310-41F10 STAND, PROPSTAND, PROP
-
209111-10058 BOLT (10X37.5)BOLT (10X37.5)
-
342321-03FK0 NUTNUT
-
409443-14066 SPRINGSPRING
-
509443-19012 SPRINGSPRING
-
643110-41F11 PEDAL, BRAKEPEDAL, BRAKE
-
743120-41F00 ARM, BRAKE RODARM, BRAKE ROD
-
843151-10F00 RUBBER, PEDALRUBBER, PEDAL
-
907120-0625A BOLTBOLT
-
1009443-12051 SPRINGSPRING
-
1101500-06207 BOLTBOLT
-
1208310-00067 NUTNUT
-
1309200-06068 PIN (6X18.2)PIN (6X18.2)
-
1408322-0106B WASHERWASHER
-
1504111-2015A COTTER PINCOTTER PIN
-
1643130-41F00 ROD, FRONTROD, FRONT
-
1743140-41F00 LINK, REAR BRAKELINK, REAR BRAKE
-
1843142-27C00 SHAFT, LINKSHAFT, LINK
-
1943151-41F00 RUBBERRUBBER
