DECALS для Yamaha BIG BEAR 400 2WD YFM400NR (5GW9) - 2003 года выпуска
-
№АртикулНазвание
-
14XE-F1568-00-00 LABEL, WARNINGLABEL, WARNING
-
24XE-F415A-00-00 LABEL, CAUTIONLABEL, CAUTION
-
34XE-F1539-10-00 RIVETRIVET
-
44XE-F1549-00-00 WASHER, FENDER MOLDWASHER, FENDER MOLD
-
55FU-F1578-00-00 LABEL, SHIFT PATTERNLABEL, SHIFT PATTERN
-
65FU-F173G-B0-00 EMBLEM SET 1 (OPT) FOR ROMANTIQUE ROUGE (RTR)EMBLEM SET 1 (OPT) FOR ROMANTIQUE ROUGE (RTR)
-
65FU-F173G-D0-00 EMBLEM SET 1 (OPT) FOR PASTEL DEEP GREEN (PDG)EMBLEM SET 1 (OPT) FOR PASTEL DEEP GREEN (PDG)
-
65FU-F173G-C0-00 EMBLEM SET 1 (OPT) FOR PASTEL DEEP GREEN (PDG)EMBLEM SET 1 (OPT) FOR PASTEL DEEP GREEN (PDG)
-
75FU-F175B-01-00 TUNING FORK MARKTUNING FORK MARK
-
85ND-F4877-00-00 LABEL, CAUTIONLABEL, CAUTION
-
95FU-F1696-00-00 LABEL, CAUTIONLABEL, CAUTION
-
104XE-F1539-10-00 RIVETRIVET
-
114XE-F1549-00-00 WASHER, FENDER MOLDWASHER, FENDER MOLD
-
125ND-F4897-00-00 EMBLEMEMBLEM
