CARBURETOR для Yamaha V STAR 1100 SILVERADO (5YSX/5YSY) [XVS11ATW/C] - 2007 года выпуска
-
№АртикулНазвание
-
15YS-14900-00-00 CARBURETOR ASSY (CALIF ONLY) (ATWC 5YSY)CARBURETOR ASSY (CALIF ONLY) (ATWC 5YSY)
-
15YS-14906-00-00 CARBURETOR ASSY (EXCEPT CALIF) (ATW 5YS1)CARBURETOR ASSY (EXCEPT CALIF) (ATW 5YS1)
-
25YS-14901-00-00 ...CARBURETOR ASSY 1 (#1) (REAR)...CARBURETOR ASSY 1 (#1) (REAR)
-
35YS-14902-00-00 ...CARBURETOR ASSY 2 (#2) (FRONT)...CARBURETOR ASSY 2 (#2) (FRONT)
-
45EL-14112-00-00 .........VALVE, THROTTLE 1.........VALVE, THROTTLE 1
-
55EL-1490J-00-00 .........NEEDLE SET.........NEEDLE SET
-
65EL-14107-12-00 .........NEEDLE VALVE SET.........NEEDLE VALVE SET
-
7127-14186-00-00 .........PIN, FLOAT.........PIN, FLOAT
-
83G2-1423A-73-00 .........JET, MAIN (#112.5) (#1) (REAR).........JET, MAIN (#112.5) (#1) (REAR)
-
83G2-14231-23-00 .........JET, MAIN (#115) (#2) (FRONT).........JET, MAIN (#115) (#2) (FRONT)
-
9583-14561-00-00 .........O-RING.........O-RING
-
105KS-14261-00-00 .........HOLDER.........HOLDER
-
115DM-14561-00-00 .........O-RING.........O-RING
-
125EL-24411-00-00 .........DIAPHRAGM.........DIAPHRAGM
-
134KM-14933-00-00 .........SPRING, DIAPHRAGM.........SPRING, DIAPHRAGM
-
144XY-14105-00-00 .........PILOT SCREW SET.........PILOT SCREW SET
-
1598502-05016-00 .........SCREW, PAN HEAD (#1) (REAR).........SCREW, PAN HEAD (#1) (REAR)
-
161HX-14231-29-00 .........JET, MAIN (#145).........JET, MAIN (#145)
-
175EL-1410A-00-00 .........STARTER SET.........STARTER SET
-
184KM-14142-17-00 .........JET, PILOT (#17.5).........JET, PILOT (#17.5)
-
195EL-14918-00-00 .........RING.........RING
-
203G2-1423A-59-00 .........JET, MAIN (#42.5).........JET, MAIN (#42.5)
-
211HX-1423E-25-00 .........JET, MAIN (#63.8).........JET, MAIN (#63.8)
-
224KM-14194-00-00 .........RING (#1) ((#1) REAR).........RING (#1) ((#1) REAR)
-
23354-14147-00-00 .........O-RING.........O-RING
-
2498507-04012-00 .........SCREW, PAN HEAD (#2) ) FRONT).........SCREW, PAN HEAD (#2) ) FRONT)
-
2533M-14139-00-00 .........CLIP, PIPE (#2) (FRONT).........CLIP, PIPE (#2) (FRONT)
-
265DM-14985-00-00 .........FLOAT.........FLOAT
-
2798507-04008-00 .........SCREW, PAN HEAD.........SCREW, PAN HEAD
-
281FN-14565-00-00 .........SCREW.........SCREW
-
2998507-04014-00 .........SCREW, PAN HEAD.........SCREW, PAN HEAD
-
3092907-04100-00 .........WASHER, SPRING.........WASHER, SPRING
-
315EL-1490H-00-00 .........DIAPHRAGM SET 5.........DIAPHRAGM SET 5
-
325DM-14141-40-00 .........NOZZLE, MAIN.........NOZZLE, MAIN
-
334KM-14216-00-00 .........SCREW (#1) (REAR).........SCREW (#1) (REAR)
-
334KM-14216-00-00 .........SCREW (#2) (FRONT).........SCREW (#2) (FRONT)
-
3498507-04010-00 .........SCREW, PAN HEAD (#2) (FRONT).........SCREW, PAN HEAD (#2) (FRONT)
-
3498507-04010-00 .........SCREW, PAN HEAD (#1) (REAR).........SCREW, PAN HEAD (#1) (REAR)
-
3512R-14191-00-00 .........PLUG, DRAIN.........PLUG, DRAIN
-
365EL-14561-00-00 .........O-RING.........O-RING
-
373F9-14118-00-00 .........CAP.........CAP
-
3898507-04006-00 .........SCREW, PAN HEAD (#1) (REAR).........SCREW, PAN HEAD (#1) (REAR)
-
3990461-06087-00 .........CLAMP (#1) (REAR).........CLAMP (#1) (REAR)
-
404DH-82103-00-00 .........TERMINAL 1 (#1) (REAR).........TERMINAL 1 (#1) (REAR)
-
415FU-83790-20-00 .........HEATER ASSY (30W).........HEATER ASSY (30W)
-
4290201-08016-00 .........WASHER, PLATE.........WASHER, PLATE
-
435EL-14103-00-00 .........THROTTLE SCREW SET (#1) (REAR).........THROTTLE SCREW SET (#1) (REAR)
-
4422U-14561-00-00 .........O-RING.........O-RING
-
45256-14956-01-00 .........WASHER.........WASHER
-
4692902-04600-00 .........WASHER, PLATE (#2) (FRONT).........WASHER, PLATE (#2) (FRONT)
-
475KS-1410H-00-00 .........FUEL CUT SOLENOID VALVE (#1) REAR).........FUEL CUT SOLENOID VALVE (#1) REAR)
-
485KS-1410H-10-00 .........FUEL CUT SOLENOID VALVE (#2) (FRONT).........FUEL CUT SOLENOID VALVE (#2) (FRONT)
-
493LN-1416A-00-00 ...O-RING...O-RING
-
504SV-24453-00-00 ...SCREW...SCREW
-
515EL-14935-00-00 ...SPRING...SPRING
-
5292902-05100-00 ...WASHER, SPRING...WASHER, SPRING
-
5395302-05700-00 ...NUT...NUT
-
5411H-14991-00-00 ...SCREW...SCREW
-
5531H-14194-00-00 ...RING...RING
-
565EL-14577-00-00 ...ROD...ROD
-
575EL-14987-10-00 ...HOSE...HOSE
-
584WM-14565-00-00 ...SCREW...SCREW
-
595EL-85885-00-00 ...THROTTLE SENSOR ASSY...THROTTLE SENSOR ASSY
-
605EL-14592-00-00 ...SCREW...SCREW
-
614NK-14285-00-00 ...WASHER...WASHER
-
625KS-81517-00-00 ......WIRE, SUB LEAD......WIRE, SUB LEAD
-
635EL-14196-00-00 ......PIPE......PIPE
-
645EL-14991-00-00 ......SCREW......SCREW
-
6522F-14117-00-00 ......WASHER, PLUG SCREW......WASHER, PLUG SCREW
-
665EL-14212-00-00 ......SPRING, PILOT ADJUSTING......SPRING, PILOT ADJUSTING
-
673F7-14133-00-00 ......SPRING, THROTTLE STOP......SPRING, THROTTLE STOP
-
685EL-14197-10-00 ......PIPE......PIPE
-
691A8-14953-00-00 ......WASHER......WASHER
-
70812-14137-00-00 ......CLIP......CLIP
-
7135H-14139-00-00 ......CLIP, PIPE......CLIP, PIPE
-
7291492-10008-00 ...PIN, COTTER...PIN, COTTER
-
7392906-06100-00 ...WASHER, SPRING...WASHER, SPRING
-
7495382-06700-00 ...NUT...NUT
-
755EL-14149-00-00 ...PIPE...PIPE
-
765EL-14251-00-00 ...NIPPLE...NIPPLE
-
7798507-04010-00 ......SCREW, PAN HEAD......SCREW, PAN HEAD
-
7892902-06600-00 ...WASHER, PLATE...WASHER, PLATE
-
791FK-14179-00-00 ...WASHER, STARTER LEVER...WASHER, STARTER LEVER
-
805EL-14592-10-00 ...SCREW...SCREW
-
814X7-2149Y-00-00 ...FILTER ASSY...FILTER ASSY
-
828A7-14139-00-00 ...CLIP, PIPE...CLIP, PIPE
-
83895-14169-00-00 ...CAP...CAP
-
845EL-14987-20-00 ......HOSE......HOSE
-
8555X-14937-00-00 ......CLIP......CLIP
-
865GK-1491A-00-00 ......CAP......CAP
