DRIVE SHAFT для Yamaha FJR1300A - 2008 года выпуска

№

Артикул

Название
1

3P6-W4612-20-00 REAR AXLE GEAR CASE ASSY

REAR AXLE GEAR CASE ASSY

165 840 ₽
2

90116-10010-00 ...BOLT, STUD

...BOLT, STUD

850 ₽
3

90116-08025-00 ...BOLT, STUD

...BOLT, STUD

290 ₽
4

5JW-46153-00-00 ...COLLAR, GUIDE

...COLLAR, GUIDE

2 200 ₽
5

93101-30084-00 ...OIL SEAL, S-TYPE

...OIL SEAL, S-TYPE

1 420 ₽
6

93311-43729-00 ...BEARING, CYL.#11

...BEARING, CYL.#11

6 920 ₽
7

2H7-46102-00-00 ...BEARING ASSY

...BEARING ASSY

3 460 ₽
8

1J7-17537-Y0-30 ...SHIM, THRUST (0.30T) (OPT)

...SHIM, THRUST (0.30T) (OPT)

370 ₽
8

1J7-17537-Y0-40 ...SHIM, THRUST (0.40T) (OPT)

...SHIM, THRUST (0.40T) (OPT)

370 ₽
8

1J7-17537-Y0-50 ...SHIM, THRUST (0.50T) (OPT)

...SHIM, THRUST (0.50T) (OPT)

370 ₽
9

93306-30533-00 ...BEARING

...BEARING

10 860 ₽
10

4H7-46125-00-00 ...RETAINER, BEARING

...RETAINER, BEARING

3 300 ₽
11

93210-60426-00 ...O-RING

...O-RING

890 ₽
12

93101-38001-00 ...OIL SEAL

...OIL SEAL

1 030 ₽
13

3P6-46123-01-00 ...COUPLING, GEAR

...COUPLING, GEAR

14 170 ₽
14

90201-166R5-00 ...WASHER, PLATE

...WASHER, PLATE

1 730 ₽
15

90179-16010-00 ...NUT

...NUT

2 990 ₽
16

3P6-46152-00-00 ...HOUSING, BEARING

...HOUSING, BEARING

13 700 ₽
17

1J7-46117-Y0-25 ...SHIM, RING GEAR (0.25T) (OPT)

...SHIM, RING GEAR (0.25T) (OPT)

440 ₽
17

1J7-46117-Y0-30 ...SHIM, RING GEAR (0.30T) (OPT)

...SHIM, RING GEAR (0.30T) (OPT)

440 ₽
17

1J7-46117-Y0-40 ...SHIM, RING GEAR (0.40T) (OPT)

...SHIM, RING GEAR (0.40T) (OPT)

440 ₽
17

1J7-46117-Y0-50 ...SHIM, RING GEAR (0.50T) (OPT)

...SHIM, RING GEAR (0.50T) (OPT)

440 ₽
18

93316-01403-00 ...BEARING, CYL.#16

...BEARING, CYL.#16

7 550 ₽
19

22U-46118-00-12 ...SHIM, THRUST (1.2T) (OPT)

...SHIM, THRUST (1.2T) (OPT)

750 ₽
19

22U-46118-00-14 ...SHIM, THRUST (1.4T) (OPT)

...SHIM, THRUST (1.4T) (OPT)

750 ₽
19

22U-46118-00-16 ...SHIM, THRUST (1.6T) (OPT)

...SHIM, THRUST (1.6T) (OPT)

750 ₽
19

22U-46118-00-18 ...SHIM, THRUST (1.8T) (OPT)

...SHIM, THRUST (1.8T) (OPT)

750 ₽
19

22U-46118-00-20 ...SHIM, THRUST (2.0T) (OPT)

...SHIM, THRUST (2.0T) (OPT)

750 ₽
20

93211-54698-00 ...O-RING

...O-RING

2 200 ₽
21

95312-08600-00 ...NUT (6L2)

...NUT (6L2)

540 ₽
22

90204-08001-00 ...WASHER, SPRING

...WASHER, SPRING

70 ₽
23

95812-10050-00 ...BOLT, WASHER BASED

...BOLT, WASHER BASED

480 ₽
24

93102-70167-00 ...OIL SEAL, SD-TYPE

...OIL SEAL, SD-TYPE

2 040 ₽
25

90340-14132-00 ...PLUG, STRAIGHT SCREW

...PLUG, STRAIGHT SCREW

250 ₽
26

214-11198-01-00 ...GASKET

...GASKET

260 ₽
27

2H7-17590-00-00 ...BREATHER COMP.

...BREATHER COMP.

1 550 ₽
28

90340-14004-00 ...PLUG, STRAIGHT SCREW

...PLUG, STRAIGHT SCREW

1 200 ₽
29

1FK-46154-00-00 ...COVER, HOUSING

...COVER, HOUSING

3 300 ₽
30

1FK-46156-00-00 ...STOPPER, RING GEAR

...STOPPER, RING GEAR

1 730 ₽
31

1FK-46157-00-15 ...SHIM, STOPPER (T=0.15) (OPT)

...SHIM, STOPPER (T=0.15) (OPT)

150 ₽
31

1FK-46157-00-20 ...SHIM, STOPPER (T=0.20) (OPT)

...SHIM, STOPPER (T=0.20) (OPT)

150 ₽
32

5VS-4615A-00-00 COLLAR, GUIDE 1

COLLAR, GUIDE 1

4 400 ₽
33

3P6-46172-10-00 SHAFT, DRIVE

SHAFT, DRIVE

24 250 ₽
34

93108-43001-00 OIL SEAL

OIL SEAL

3 300 ₽
35

90201-23008-00 WASHER, PLATE

WASHER, PLATE

310 ₽
36

93410-23056-00 CIRCLIP, S-TYPE

CIRCLIP, S-TYPE

280 ₽
37

93410-22039-00 CIRCLIP, S-TYPE

CIRCLIP, S-TYPE

470 ₽
38

5JW-46180-00-00 CROSS JOINT COMP.

CROSS JOINT COMP.

38 270 ₽
39

90501-16491-00 SPRING, COMPRESSION

SPRING, COMPRESSION

370 ₽
40

90176-10075-00 NUT, CROWN

NUT, CROWN

650 ₽
41

92990-10600-00 WASHER, PLATE

WASHER, PLATE

290 ₽
