COWLING 2 для Yamaha R6S [ YZFR6SX/C] (6P67/6P68) - 2008 года выпуска
-
№АртикулНазвание
-
15SL-Y283U-P0-P1 PANEL ASSEMBLY 1 (OPT) (FOR DPBMC)PANEL ASSEMBLY 1 (OPT) (FOR DPBMC)
-
15SL-Y283U-R0-P0 PANEL ASSEMBLY 1 (OPT) (MBL2 FOR SMX)PANEL ASSEMBLY 1 (OPT) (MBL2 FOR SMX)
-
290387-06057-00 ...COLLAR...COLLAR
-
390480-14003-00 ...GROMMET...GROMMET
-
45SL-2836T-00-00 ...DAMPER, LOCATING 1...DAMPER, LOCATING 1
-
54P6-28391-10-00 ...GRAPHIC 1 (OPT) (FOR DPBMC)...GRAPHIC 1 (OPT) (FOR DPBMC)
-
64P6-28315-30-00 ...EMBLEM (OPT) (FOR DPBMC)...EMBLEM (OPT) (FOR DPBMC)
-
64P6-28315-40-00 ...EMBLEM (OPT) (FOR SMX)...EMBLEM (OPT) (FOR SMX)
-
75SL-Y283V-P0-P1 PANEL ASSEMBLY 2 (OPT) (FOR DPBMC)PANEL ASSEMBLY 2 (OPT) (FOR DPBMC)
-
75SL-Y283V-R0-P0 PANEL ASSEMBLY 2 (OPT) (MBL2 FOR SMX)PANEL ASSEMBLY 2 (OPT) (MBL2 FOR SMX)
-
890387-06057-00 ...COLLAR...COLLAR
-
990480-14003-00 ...GROMMET...GROMMET
-
105SL-2836U-00-00 ...DAMPER, LOCATING 2...DAMPER, LOCATING 2
-
114P6-28392-10-00 ...GRAPHIC 2 (OPT) (FOR DPBMC)...GRAPHIC 2 (OPT) (FOR DPBMC)
-
124P6-28315-30-00 ...EMBLEM (OPT) (FOR DPBMC)...EMBLEM (OPT) (FOR DPBMC)
-
124P6-28315-40-00 ...EMBLEM (OPT) (FOR SMX)...EMBLEM (OPT) (FOR SMX)
-
1390111-05003-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
1490202-05180-00 WASHER, PLATEWASHER, PLATE
-
1590111-06040-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
165SL-2836K-00-00 PANEL, INNER 1PANEL, INNER 1
-
175SL-2836L-00-00 PANEL, INNER 2PANEL, INNER 2
-
1890269-06008-00 RIVETRIVET
-
195SL-Y2808-C0-P4 COVER ASSY, UNDER (OPT) (FOR SMX)COVER ASSY, UNDER (OPT) (FOR SMX)
-
195SL-Y2808-A0-P4 COVER ASSY, UNDER (OPT) (SMX FOR DPBMC)COVER ASSY, UNDER (OPT) (SMX FOR DPBMC)
-
205SL-2843J-00-00 ...COVER 3...COVER 3
-
2190183-05024-00 ...NUT, SPRING...NUT, SPRING
-
2290480-14003-00 ...GROMMET...GROMMET
-
2390387-06057-00 ...COLLAR...COLLAR
-
2490183-05061-00 ...NUT, SPRING...NUT, SPRING
-
2590111-05002-00 ...BOLT, HEX. SOCKET BUTTON...BOLT, HEX. SOCKET BUTTON
-
265SL-2834E-00-00 ......DAMPER 3......DAMPER 3
-
275SL-2837J-00-00 ......DAMPER 5......DAMPER 5
-
281HX-27415-00-00 ...PLATE, DAMPER...PLATE, DAMPER
-
295SL-21649-00-00 ......DAMPER......DAMPER
-
3099241-00280-00 ...EMBLEM, YAMAHA (OPT) (FOR DPBMC)...EMBLEM, YAMAHA (OPT) (FOR DPBMC)
-
314P6-28328-00-00 ...EMBLEM (OPT) (FOR SMX)...EMBLEM (OPT) (FOR SMX)
-
324P6-2834C-00-00 ...EMBLEM 1 (OPT) (FOR SMX)...EMBLEM 1 (OPT) (FOR SMX)
-
334P6-28338-00-00 ...EMBLEM (OPT) (FOR SMX)...EMBLEM (OPT) (FOR SMX)
-
344P6-2153E-01-00 ...EMBLEM, YAMAHA (OPT) (FOR SMX)...EMBLEM, YAMAHA (OPT) (FOR SMX)
-
355SL-Y2809-D0-P4 COVER ASSY 2, UNDER (OPT) (FOR SMX)COVER ASSY 2, UNDER (OPT) (FOR SMX)
-
355SL-W2809-00-P4 COVER ASSY 2, UNDER (OPT) (SMX FOR DPBMC)COVER ASSY 2, UNDER (OPT) (SMX FOR DPBMC)
-
365SL-2844J-00-00 ...COVER 4...COVER 4
-
3790183-05024-00 ...NUT, SPRING...NUT, SPRING
-
3890480-14003-00 ...GROMMET...GROMMET
-
3990387-06057-00 ...COLLAR...COLLAR
-
4090183-05061-00 ...NUT, SPRING...NUT, SPRING
-
4190111-05002-00 ...BOLT, HEX. SOCKET BUTTON...BOLT, HEX. SOCKET BUTTON
-
425SL-2834F-00-00 ...DAMPER...DAMPER
-
435SL-2837K-00-00 ...DAMPER 6...DAMPER 6
-
445SL-2838G-00-00 ...SEAT 1...SEAT 1
-
455SL-2848K-00-00 ...SEAT 2...SEAT 2
-
4699241-00280-00 ...EMBLEM, YAMAHA (OPT) (FOR DPBMC)...EMBLEM, YAMAHA (OPT) (FOR DPBMC)
-
474P6-28328-00-00 ...EMBLEM (OPT) (FOR SMX)...EMBLEM (OPT) (FOR SMX)
-
484P6-2834C-00-00 ...EMBLEM 1 (OPT) (FOR SMX)...EMBLEM 1 (OPT) (FOR SMX)
-
494P6-28338-00-00 ...EMBLEM (OPT) (FOR SMX)...EMBLEM (OPT) (FOR SMX)
-
504P6-2153E-01-00 ...EMBLEM, YAMAHA (OPT) (FOR SMX)...EMBLEM, YAMAHA (OPT) (FOR SMX)
-
5190111-05003-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
5290202-05180-00 WASHER, PLATEWASHER, PLATE
-
5390111-06040-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
545SL-2836M-00-00 PANEL, INNER 3PANEL, INNER 3
-
5590183-05061-00 NUT, SPRINGNUT, SPRING
-
5690480-14003-00 ...GROMMET...GROMMET
-
5790387-06057-00 ...COLLAR...COLLAR
-
5897707-50016-00 SCREW, TRUSS HEAD TAPPINGSCREW, TRUSS HEAD TAPPING
-
5990111-05003-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
6090202-05180-00 WASHER, PLATEWASHER, PLATE
-
6190111-06040-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
