FUEL TANK для Yamaha V STAR 1100 CUSTOM - 2008 года выпуска
-
№АртикулНазвание
-
15EL-Y2410-A2-02 FUEL TANK COMP. (EXCEPT CALIF)FUEL TANK COMP. (EXCEPT CALIF)
-
15EL-Y2410-V2-X2 FUEL TANK COMP. (CALIF ONLY)FUEL TANK COMP. (CALIF ONLY)
-
25GK-2118K-00-00 LABEL, CAUTIONLABEL, CAUTION
-
35EL-24182-00-00 DAMPER, LOCATING 2DAMPER, LOCATING 2
-
44TR-24183-00-00 DAMPER, LOCATING 3DAMPER, LOCATING 3
-
590201-060S9-00 WASHER, PLATEWASHER, PLATE
-
692017-06012-00 SCREW (3GG)SCREW (3GG)
-
72YK-24181-10-00 DAMPER, LOCATING 1DAMPER, LOCATING 1
-
85BN-24602-01-00 CAP ASSYCAP ASSY
-
84NK-24602-11-00 CAP ASSYCAP ASSY
-
94WM-24500-02-00 FUEL COCK ASSY 1FUEL COCK ASSY 1
-
103AC-24523-00-00 ...VALVE PACKING...VALVE PACKING
-
113AJ-24534-01-00 ...SEAL, COCK...SEAL, COCK
-
1297801-03008-00 ...SCREW, PAN HEAD...SCREW, PAN HEAD
-
134X8-24512-00-00 ...O-RING...O-RING
-
1490149-06011-00 SCREW, SPEC'L SHAPESCREW, SPEC'L SHAPE
-
1590202-05193-00 WASHER, PLATEWASHER, PLATE
-
161FK-2171L-00-00 MOLE, SIDE COVER 1MOLE, SIDE COVER 1
-
175EL-24188-00-00 MOLD, FUEL TANKMOLD, FUEL TANK
-
183XV-21717-00-00 DAMPERDAMPER
-
195EL-24311-10-00 PIPE, FUEL 1PIPE, FUEL 1
-
205EL-24313-10-00 PIPE 3PIPE 3
-
211FK-24560-10-00 FILTER ASSYFILTER ASSY
-
221FK-24566-00-00 BRACKET, FILTERBRACKET, FILTER
-
234EB-24398-00-00 BAND 1BAND 1
-
2490467-12053-00 CLIP, SCISSORCLIP, SCISSOR
-
2590467-11028-00 CLIP, SCISSORCLIP, SCISSOR
-
265EL-2171A-00-00 COVER, TOPCOVER, TOP
-
2790202-05180-00 WASHER, PLATEWASHER, PLATE
-
2890110-05201-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
295EL-2412F-00-00 BRACKET, SEATBRACKET, SEAT
-
3090183-05061-00 NUT, SPRINGNUT, SPRING
-
3198507-05012-00 SCREW, PAN HEADSCREW, PAN HEAD
-
3292907-05600-00 WASHER, PLATE (1RW)WASHER, PLATE (1RW)
-
335EL-2414G-00-00 SEALSEAL
-
344DN-21268-00-00 SEALSEAL
-
353SP-21732-00-00 SEAL 1SEAL 1
-
365EL-24188-00-00 MOLD, FUEL TANKMOLD, FUEL TANK
-
375EL-2411F-00-00 PLATE, FITTINGPLATE, FITTING
-
3895807-08012-00 BOLT, FLANGEBOLT, FLANGE
-
3990179-05009-00 NUTNUT
-
405EL-24321-10-00 PIPE 10PIPE 10
-
414XY-14568-00-00 JOINTJOINT
-
425EL-24312-20-00 PIPE 2PIPE 2
-
435RB-24180-00-00 ROLL OVER VALVE ASSYROLL OVER VALVE ASSY
-
4490445-11056-00 HOSEHOSE
-
455EL-24170-00-00 CANISTER ASSYCANISTER ASSY
-
465EL-24316-10-00 PIPE 6PIPE 6
-
475EL-24317-10-00 PIPE 7PIPE 7
-
484WM-14896-00-00 VALVE, OUTER VENT CONTROL 2VALVE, OUTER VENT CONTROL 2
-
495EL-24315-10-00 PIPE 5PIPE 5
-
5090461-15139-00 CLAMPCLAMP
-
5197707-50016-00 SCREW, TRUSS HEAD TAPPINGSCREW, TRUSS HEAD TAPPING
-
5290105-06446-00 BOLT, FLANGEBOLT, FLANGE
-
5390150-05040-00 SCREW, ROUND HEAD (JN2)SCREW, ROUND HEAD (JN2)
-
5490467-08075-00 CLIP, SCISSORCLIP, SCISSOR
-
5590467-09103-00 CLIP, SCISSORCLIP, SCISSOR
-
5690467-10041-00 CLIP, SCISSORCLIP, SCISSOR
-
5790467-08017-00 CLIP, SCISSORCLIP, SCISSOR
-
585EL-24322-10-00 PIPE 11PIPE 11
-
595KS-13907-00-00 FUEL PUMP COMP.FUEL PUMP COMP.
-
605YS-2414H-00-00 DAMPER, PLATE 1DAMPER, PLATE 1
-
615YS-2414J-00-00 DAMPER, PLATE 2DAMPER, PLATE 2
-
625YS-2414K-00-00 DAMPER, PLATE 3DAMPER, PLATE 3
-
635YS-2414N-00-00 DAMPER, PLATE 4DAMPER, PLATE 4
