OIL COOLER для Yamaha FX CRUISER HO 3-PASS - 2008 года выпуска
-
№АртикулНазвание
-
160E-13446-00-00 CONNECTORCONNECTOR
-
293210-18322-00 O-RINGO-RING
-
36B6-13462-00-94 CASE, OIL COOLERCASE, OIL COOLER
-
490119-10020-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
56B6-13317-00-00 PLATE, BAFFLEPLATE, BAFFLE
-
691317-05014-00 BOLTBOLT
-
760E-13421-00-00 STRAINER 2STRAINER 2
-
891317-06014-00 BOLTBOLT
-
990465-13M39-00 CLAMPCLAMP
-
106AA-85542-00-00 BRACKETBRACKET
-
1190387-06M05-00 COLLARCOLLAR
-
1297595-06520-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
136E5-11325-00-00 ANODEANODE
-
1498780-04015-00 SCREW, FLAT HEADSCREW, FLAT HEAD
-
1560E-13463-10-94 COVER, OIL COOLERCOVER, OIL COOLER
-
166B6-11165-00-00 PLATE, BREATHERPLATE, BREATHER
-
176B6-11145-00-00 PLATE, BREATHER 2PLATE, BREATHER 2
-
1891317-05035-00 BOLTBOLT
-
1960E-13475-00-00 GASKETGASKET
-
2060E-13477-00-00 GASKETGASKET
-
2190105-06036-00 BOLT, FLANGEBOLT, FLANGE
-
2267F-82588-00-00 PLATE (CALIF. / NY ONLY)PLATE (CALIF. / NY ONLY)
-
2390464-20012-00 CLAMP (CALIF. / NY ONLY)CLAMP (CALIF. / NY ONLY)
-
2460E-15362-00-00 PLUG, OIL LEVELPLUG, OIL LEVEL
-
2560E-13473-00-00 O-RINGO-RING
-
266B6-11119-00-00 HANGER, ENGINEHANGER, ENGINE
-
2790119-06023-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
286D3-13443-00-94 COVER, OIL COOLERCOVER, OIL COOLER
-
2960E-13476-10-00 GASKETGASKET
-
3090105-06M07-00 BOLT,WASHER BASEDBOLT,WASHER BASED
-
316B6-13151-00-94 STAYSTAY
-
3290119-10M02-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
3390116-10016-00 BOLT, STUDBOLT, STUD
-
3490176-10001-00 NUT, CROWNNUT, CROWN
-
356B6-11167-00-00 PIPE, BREATHER 2PIPE, BREATHER 2
-
3690467-170A0-00 CLIPCLIP
-
3760E-13567-00-00 GASKETGASKET
-
3860E-13882-00-00 COVER 2COVER 2
-
3997580-06516-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
4097013-06012-00 BOLTBOLT
-
4192903-06600-00 WASHER, PLATEWASHER, PLATE
-
4260E-51341-00-94 BRACKET 1BRACKET 1
-
4392995-06600-00 WASHERWASHER
-
4491380-06020-00 BOLTBOLT
-
4590480-06M46-00 GROMMETGROMMET
