THROTTLE BODY ASSY. W/ INTAKE для Yamaha MORPHOUS - 2006 года выпуска
-
№АртикулНазвание
-
11B7-14411-00-00 CASE, AIR CLEANER 1CASE, AIR CLEANER 1
-
21B7-1441F-00-00 PARTITION, AIR CLEANER CASEPARTITION, AIR CLEANER CASE
-
31B7-14412-00-00 CAP, CLEANER CASE 1CAP, CLEANER CASE 1
-
41B7-14422-00-00 CAP, CLEANER CASE 2CAP, CLEANER CASE 2
-
51B7-14437-00-00 DUCTDUCT
-
61B7-14451-00-00 ELEMENT, AIR CLEANERELEMENT, AIR CLEANER
-
71B7-14453-00-00 JOINT, AIR CLEANER 1JOINT, AIR CLEANER 1
-
81B7-14452-00-00 SEALSEAL
-
91B7-14457-00-00 SEALSEAL
-
105XT-1443E-00-00 PIPE, DRAINPIPE, DRAIN
-
1190467-11106-00 CLIPCLIP
-
1297707-50025-00 SCREW, TAPPINGSCREW, TAPPING
-
135CA-14435-00-00 GROMMETGROMMET
-
145CA-85886-00-00 SENSOR, AIR TEMPRATURESENSOR, AIR TEMPRATURE
-
1590480-13013-00 GROMMETGROMMET
-
1690387-064W3-00 COLLARCOLLAR
-
171B7-14417-00-00 COVER 1COVER 1
-
1890109-067E6-00 BOLTBOLT
-
195VG-13575-00-00 BANDBAND
-
2090338-12004-00 PLUGPLUG
