CARBURETOR ASSY для Yamaha SRX 700 - 2001 года выпуска
-
№АртикулНазвание
-
18DN-14100-11-00 CARBURETOR ASSYCARBURETOR ASSY
-
28DN-14101-11-00 ...CARBURETOR ASSY 1...CARBURETOR ASSY 1
-
38DN-14102-11-00 ...CARBURETOR ASSY 2...CARBURETOR ASSY 2
-
48DN-14103-11-00 ...THROTTLE SCREW SET...THROTTLE SCREW SET
-
589A-14292-00-00 LEVER A (2)LEVER A (2)
-
689A-14243-00-00 PLATEPLATE
-
789A-14137-00-00 CLIPCLIP
-
889A-14199-00-00 GASKETGASKET
-
991316-03012-00 BOLTBOLT
-
1089A-14188-00-00 CONNECTORCONNECTOR
-
113GF-14126-00-00 GASKETGASKET
-
12620-14198-00-00 GASKETGASKET
-
133MA-14937-00-00 CLIPCLIP
-
143FA-14137-00-00 CLIPCLIP
-
158AB-14227-00-00 WASHER (T=0.4MM)WASHER (T=0.4MM)
-
1689A-14112-25-00 VALVE, THROTTLE 1VALVE, THROTTLE 1
-
173H1-14147-00-00 O-RINGO-RING
-
183H1-14962-00-00 WASHERWASHER
-
195K7-14134-00-00 SPRING, AIR ADJUSTINGSPRING, AIR ADJUSTING
-
2089A-14565-00-00 SCREW, PILOT ADJUSTINGSCREW, PILOT ADJUSTING
-
213H1-14142-37-00 JET, PILOT (37.5) (OPT)JET, PILOT (37.5) (OPT)
-
213H1-14142-40-00 JET, PILOT (40) (STD)JET, PILOT (40) (STD)
-
213H1-14142-42-00 JET, PILOT (42.5) (OPT)JET, PILOT (42.5) (OPT)
-
213H1-14142-45-00 JET, PILOT (45) (OPT)JET, PILOT (45) (OPT)
-
213H1-14142-47-00 JET, PILOT (47.5) (OPT)JET, PILOT (47.5) (OPT)
-
213H1-14142-50-00 JET, PILOT (50) (OPT)JET, PILOT (50) (OPT)
-
213H1-14142-52-00 JET, PILOT (52.5) (OPT)JET, PILOT (52.5) (OPT)
-
2289A-14996-00-00 PIPEPIPE
-
238BU-14116-26-00 NEEDLENEEDLE
-
248CH-14141-56-00 NOZZLE, MAINNOZZLE, MAIN
-
251LX-14153-00-00 WASHER, MAIN JETWASHER, MAIN JET
-
2689A-14194-00-00 RINGRING
-
273G2-14231-27-00 JET, MAIN (135) (OPT)JET, MAIN (135) (OPT)
-
273G2-14231-28-00 JET, MAIN (140) (OPT)JET, MAIN (140) (OPT)
-
273G2-14231-29-00 JET, MAIN (145) (OPT)JET, MAIN (145) (OPT)
-
273G2-14231-30-00 JET, MAIN (150) (OPT)JET, MAIN (150) (OPT)
-
273G2-14231-30-00 JET, MAIN (150) (STD) (CARB 1)JET, MAIN (150) (STD) (CARB 1)
-
273G2-14231-81-00 JET, MAIN (152.5) (OPT)JET, MAIN (152.5) (OPT)
-
273G2-1423A-77-00 JET, MAIN (132.5) (OPT)JET, MAIN (132.5) (OPT)
-
273G2-1423A-78-00 JET, MAIN (137.5) (OPT)JET, MAIN (137.5) (OPT)
-
273G2-1423A-79-00 JET, MAIN (142.5) (OPT)JET, MAIN (142.5) (OPT)
-
273G2-1423A-80-00 JET, MAIN (147.5) (OPT)JET, MAIN (147.5) (OPT)
-
273G2-1423E-53-00 JET, MAIN (133.8) (OPT)JET, MAIN (133.8) (OPT)
-
273G2-1423E-54-00 JET, MAIN (136.3) (OPT)JET, MAIN (136.3) (OPT)
-
273G2-1423E-55-00 JET, MAIN (138.8) (OPT)JET, MAIN (138.8) (OPT)
-
273G2-1423E-56-00 JET, MAIN (141.3) (OPT)JET, MAIN (141.3) (OPT)
-
273G2-1423E-57-00 JET, MAIN (143.8) (OPT)JET, MAIN (143.8) (OPT)
-
273G2-1423E-58-00 JET, MAIN (146.3) (OPT)JET, MAIN (146.3) (OPT)
-
273G2-1423E-59-00 JET, MAIN (148.8) (OPT)JET, MAIN (148.8) (OPT)
-
273G2-1423E-59-00 JET, MAIN (148.8) (STD) (CARBS 2,3)JET, MAIN (148.8) (STD) (CARBS 2,3)
-
273G2-1423E-60-00 JET, MAIN (151.3) (OPT)JET, MAIN (151.3) (OPT)
-
28500-14115-00-00 PLUG, SCREWPLUG, SCREW
-
29558-14147-00-00 O-RINGO-RING
-
302LN-14565-00-00 SCREWSCREW
-
311UY-14185-00-00 FLOATFLOAT
-
32537-14186-00-00 PIN, FLOATPIN, FLOAT
-
331AE-14190-13-00 NEEDLE VALVE ASSYNEEDLE VALVE ASSY
-
3489A-14147-00-00 O-RINGO-RING
-
358F2-14147-00-00 O-RINGO-RING
-
36239-14172-10-00 PILOT JET, AIR (1.0)PILOT JET, AIR (1.0)
-
3798702-05008-00 SCREW, FLAT HEAD (CARB 2)SCREW, FLAT HEAD (CARB 2)
-
38302-14173-00-00 COVER, PLUNGER CAPCOVER, PLUNGER CAP
-
394G0-14171-00-00 PLUNGER, STARTERPLUNGER, STARTER
-
401AW-14135-00-00 SPRING, PLUNGERSPRING, PLUNGER
-
411FN-14174-00-00 CAP, PLUNGERCAP, PLUNGER
-
421AE-14147-00-00 O-RINGO-RING
-
4389A-14216-00-00 SCREW (CARBS 1,3)SCREW (CARBS 1,3)
-
4495302-05700-00 NUT (CARBS 1,3)NUT (CARBS 1,3)
-
4589A-14276-00-00 LEVER (CARBS 1,3)LEVER (CARBS 1,3)
-
4689A-14286-00-00 SPRING (CARBS 1,3)SPRING (CARBS 1,3)
-
4789A-14905-00-00 LEVER, STARTER (CARBS 1,3)LEVER, STARTER (CARBS 1,3)
-
4898501-04014-00 SCREW, PAN HEADSCREW, PAN HEAD
-
4912R-14191-00-00 PLUG, DRAINPLUG, DRAIN
-
5084M-14197-00-00 PIPE (CARBS 1,3)PIPE (CARBS 1,3)
-
518CH-14348-00-00 PIPE 1 (CARBS 1,3)PIPE 1 (CARBS 1,3)
-
5298502-04010-00 SCREW, PAN HEAD (CARB 2)SCREW, PAN HEAD (CARB 2)
-
533MA-14918-00-00 RINGRING
-
548CC-14122-00-00 SCREW, THROTTLE (CARB 2)SCREW, THROTTLE (CARB 2)
-
552J2-14133-00-00 SPRING, THROTTLE STOP (CARB 2)SPRING, THROTTLE STOP (CARB 2)
-
5689A-14265-00-00 COLLAR (CARB 2)COLLAR (CARB 2)
-
5722F-14117-00-00 WASHER, PLUG SCREW (CARB 2)WASHER, PLUG SCREW (CARB 2)
-
581UF-14952-00-00 WASHER (CARB 2)WASHER (CARB 2)
-
5989A-14594-00-00 NUT (CARB 2)NUT (CARB 2)
-
6089A-24529-00-00 SPRING (CARB 2)SPRING (CARB 2)
-
6187S-8259A-00-00 SWITCH, CARBURETOR (CARB 2)SWITCH, CARBURETOR (CARB 2)
-
621J7-14994-00-00 NET, FILTERNET, FILTER
-
6389A-14198-00-00 ...GASKET...GASKET
-
6497606-04110-00 ...SCREW...SCREW
-
6598702-04014-00 ...SCREW, FLAT HEAD...SCREW, FLAT HEAD
-
6689A-14208-00-00 ...LEVER COMP. 1...LEVER COMP. 1
-
6711H-14991-00-00 ...SCREW...SCREW
-
6889A-14264-00-00 ...COLLAR...COLLAR
-
698CH-14589-00-00 ...SPRING...SPRING
-
703H1-14227-00-00 ...WASHER...WASHER
-
7187M-14137-00-00 ...CLIP...CLIP
-
7297602-04116-00 ...SCREW, PAN HEAD WITH WASHER...SCREW, PAN HEAD WITH WASHER
-
7398502-05012-00 ...SCREW, PAN HEAD...SCREW, PAN HEAD
-
748CH-14978-00-00 ...SHAFT, STARTER LEVER...SHAFT, STARTER LEVER
-
7535H-14139-00-00 ...CLIP, PIPE...CLIP, PIPE
-
7697602-05110-00 ...SCREW, PAN HEAD WITH WASHER...SCREW, PAN HEAD WITH WASHER
-
7722F-14115-00-00 ...PLUG, SCREW...PLUG, SCREW
-
7822F-14117-00-00 ...WASHER, PLUG SCREW...WASHER, PLUG SCREW
-
793FV-14962-00-00 ...WASHER...WASHER
-
801AE-14135-00-00 ...SPRING, PLUNGER...SPRING, PLUNGER
-
8189A-14118-00-00 ...CAP...CAP
-
8289A-14588-00-00 ...LEVER...LEVER
-
838A7-14197-00-00 ...PIPE...PIPE
-
848F2-14197-00-00 ...PIPE...PIPE
-
854N0-14251-00-00 ...NIPPLE...NIPPLE
-
868CH-14987-10-00 ...HOSE...HOSE
-
8790467-10035-00 ...CLIP...CLIP
-
885FL-85885-00-00 ...THROTTLE SENSOR ASSY...THROTTLE SENSOR ASSY
-
898CC-14216-10-00 ...SCREW...SCREW
-
908DN-82309-00-00 ...WIRE, SUB LEAD...WIRE, SUB LEAD
