HANDLEBAR PAD W/ STEERING GATE для Yamaha APEX - 2012 года выпуска
-
№АртикулНазвание
-
18HG-23870-01-00 STEERING GATE COMP.STEERING GATE COMP.
-
28HG-23376-00-00 ...STOPPER...STOPPER
-
38FA-24768-00-00 ...STOPPER...STOPPER
-
490201-10032-00 WASHER, PLATEWASHER, PLATE
-
58HG-238B6-00-00 COVER, MOTORCOVER, MOTOR
-
690102-08006-00 BOLT, WITH HOLEBOLT, WITH HOLE
-
790109-063F1-00 BOLTBOLT
-
8JT1-83614-00-00 BRACKETBRACKET
-
998902-06016-00 SCREW, BINDSCREW, BIND
-
1090201-087H6-00 WASHER, PLATEWASHER, PLATE
-
1195702-08500-00 NUT, FLANGENUT, FLANGE
-
1290105-08236-00 BOLT, FLANGEBOLT, FLANGE
-
1390201-08326-00 WASHER, PLATEWASHER, PLATE
-
1495822-08030-00 BOLT, FLANGEBOLT, FLANGE
-
158FA-2389E-00-00 LATCHLATCH
-
1695602-08200-00 NUT, SELF-LOCKINGNUT, SELF-LOCKING
-
1790462-10022-00 CLAMPCLAMP
-
1890468-12006-00 CLIPCLIP
