REAR RACK- BODY PANEL- AND FOOTWELL ASSEMBLIES для Arctic Cat 1000 LTD GREEN-BLACK [A2011UIEW1PUSM] - 2011 года выпуска
-
№АртикулНазвание
-
12506-125 RACK, REAR - ASSEMBLY (INC. 2-3)RACK, REAR - ASSEMBLY (INC. 2-3)
-
20411-648 ...DECAL, WARNING - LOAD...DECAL, WARNING - LOAD
-
30441-592 ...BUSHING...BUSHING
-
48410-830 SCREW, CAPSCREW, CAP
-
50423-669 SPACERSPACER
-
60423-465 GROMMETGROMMET
-
78432-802 NUT, LOCKNUT, LOCK
-
80423-654 SCREW, SHOULDERSCREW, SHOULDER
-
98050-222 WASHERWASHER
-
100423-540 NUT, LOCKNUT, LOCK
-
110411-965 DECAL, "SPEEDRACK"DECAL, "SPEEDRACK"
-
120423-101 SCREW, SHOULDERSCREW, SHOULDER
-
132506-450 FOOTWELL - RIGHTFOOTWELL - RIGHT
-
131406-519 FOOTWELL - LEFTFOOTWELL - LEFT
-
140423-419 SCREW, MACHINESCREW, MACHINE
-
151506-125 FOOTPEGFOOTPEG
-
160423-355 SCREW, SHOULDERSCREW, SHOULDER
-
172516-952 PANEL, FENDER - ASSEMBLY - REAR - BLACK (INC. 18-21)PANEL, FENDER - ASSEMBLY - REAR - BLACK (INC. 18-21)
-
181411-592 ...DECAL, REFLECTOR - RIGHT - RED...DECAL, REFLECTOR - RIGHT - RED
-
181411-593 ...DECAL, REFLECTOR - LEFT - RED...DECAL, REFLECTOR - LEFT - RED
-
190470-658 ...FOIL, PROTECTIVE...FOIL, PROTECTIVE
-
202411-143 ...DECAL, WARNING - TIRE PRESSURE...DECAL, WARNING - TIRE PRESSURE
-
211411-809 ...DECAL, PASSENGER...DECAL, PASSENGER
-
222411-403 DECAL, "ARCTIC CAT"DECAL, "ARCTIC CAT"
-
232411-408 DECAL, SIDE - UPPER RIGHTDECAL, SIDE - UPPER RIGHT
-
232411-409 DECAL, SIDE - UPPER LEFTDECAL, SIDE - UPPER LEFT
-
242411-406 DECAL, 1000 - RIGHTDECAL, 1000 - RIGHT
-
242411-407 DECAL, 1000 - LEFTDECAL, 1000 - LEFT
-
252411-404 DECAL, SIDE - LOWER RIGHTDECAL, SIDE - LOWER RIGHT
-
252411-405 DECAL, SIDE - LOWER LEFTDECAL, SIDE - LOWER LEFT
