FRONT SUSPENSION SHOCK ABSORBER для Arctic Cat Wildcat 4 1000 - BLACK [U2013W4W1PUSQ] - 2013 года выпуска
-
№АртикулНазвание
-
-0403-344 COMPLETE SHOCK ABSORBERCOMPLETE SHOCK ABSORBER
-
10403-367 EYELETEYELET
-
21604-664 BEARINGBEARING
-
33604-147 RING, RETAININGRING, RETAINING
-
40603-680 O-RINGO-RING
-
50403-347 SPACERSPACER
-
60403-370 ROD, SHOCKROD, SHOCK
-
70403-361 BUMPER, SHOCKBUMPER, SHOCK
-
80403-379 END CAP, SHOCKEND CAP, SHOCK
-
90403-393 KIT, SEAL/CAP REBUILDKIT, SEAL/CAP REBUILD
-
100604-992 RING, RETAININGRING, RETAINING
-
110403-371 SPACERSPACER
-
122604-449 WASHER, TOP OUTWASHER, TOP OUT
-
130403-382 VALVE, 0.900 X 0.012 IN.VALVE, 0.900 X 0.012 IN.
-
142604-481 VALVE, 0.950 X 0.012 IN.VALVE, 0.950 X 0.012 IN.
-
152604-487 VALVE, 1.100 X 0.012 IN.VALVE, 1.100 X 0.012 IN.
-
162604-687 VALVE, 1.250 X 0.012 IN.VALVE, 1.250 X 0.012 IN.
-
172604-493 VALVE, 1.350 X 0.012 IN.VALVE, 1.350 X 0.012 IN.
-
182604-498 VALVE, 1.425 X 0.012 IN.VALVE, 1.425 X 0.012 IN.
-
192604-503 VALVE, 1.600 X 0.012 IN.VALVE, 1.600 X 0.012 IN.
-
200403-381 VALVE, 1.250 X 0.004 IN.VALVE, 1.250 X 0.004 IN.
-
212604-502 VALVE, 1.600 X 0.010 IN.VALVE, 1.600 X 0.010 IN.
-
220403-385 VALVE, 1.600 X 0.006 IN.VALVE, 1.600 X 0.006 IN.
-
230403-394 PISTON, HIGH-FLOWPISTON, HIGH-FLOW
-
242604-496 VALVE, 1.425 X 0.008 IN.VALVE, 1.425 X 0.008 IN.
-
250403-384 VALVE, 0.750 X 0.008 IN.VALVE, 0.750 X 0.008 IN.
-
262604-491 VALVE, 1.350 X 0.008 IN.VALVE, 1.350 X 0.008 IN.
-
272604-685 VALVE, 1.250 X 0.008 IN.VALVE, 1.250 X 0.008 IN.
-
282604-485 VALVE, 1.100 X 0.008 IN.VALVE, 1.100 X 0.008 IN.
-
292604-479 VALVE, 0.950 X 0.008 IN.VALVE, 0.950 X 0.008 IN.
-
300403-383 WASHER, TOP OUTWASHER, TOP OUT
-
313604-184 WASHER, BACKUPWASHER, BACKUP
-
320403-362 NUTNUT
-
330403-366 BODY, SHOCKBODY, SHOCK
-
340403-346 SLEEVE, WEARSLEEVE, WEAR
-
350404-368 NUT, ADJUSTERNUT, ADJUSTER
-
360403-352 SEAT, SPRINGSEAT, SPRING
-
370403-350 NUT, ADJUSTERNUT, ADJUSTER
-
380403-348 COLLAR, LOCKING - ADJUSTER NUTCOLLAR, LOCKING - ADJUSTER NUT
-
390403-363 DECAL, SHOCKDECAL, SHOCK
-
400403-376 END CAP, SHOCK/RESERVOIREND CAP, SHOCK/RESERVOIR
-
410403-369 RESERVOIRRESERVOIR
-
420403-377 PISTON, INTERNAL FLOATING (INC. 43-44)PISTON, INTERNAL FLOATING (INC. 43-44)
-
431604-316 ...SCREW, MACHINE W/O-RING (INC. 44)...SCREW, MACHINE W/O-RING (INC. 44)
-
441604-425 ......O-RING (FOX ONLY)......O-RING (FOX ONLY)
-
453604-517 END CAP, RESERVOIR (INC. 46-48)END CAP, RESERVOIR (INC. 46-48)
-
461604-428 ...PLUG...PLUG
-
472603-338 ...SCREW, SET...SCREW, SET
-
482603-337 ...BALL...BALL
-
490403-380 PISTON, CONCENTRIC - DAMPING ADJUSTERPISTON, CONCENTRIC - DAMPING ADJUSTER
-
505639-530 OIL, SHOCK - 1 QTOIL, SHOCK - 1 QT
-
510403-345 RETAINER, SPRINGRETAINER, SPRING
