FRONT SUSPENSION ASSEMBLY для Arctic Cat PROWLER 1000 XTZ 4X4 [U2014P4W1POSE] (INTERNATIONAL) - 2014 года выпуска
-
№АртикулНазвание
-
10423-920 RETAINER, SPRINGRETAINER, SPRING
-
20503-437 SPRING, SUSPENSION - WHITESPRING, SUSPENSION - WHITE
-
30403-215 SHOCK ABSORBER (INC. 4)SHOCK ABSORBER (INC. 4)
-
40423-917 ...SLEEVE, SHOCK - THREADED...SLEEVE, SHOCK - THREADED
-
50423-919 NUT, SPRING RETAINERNUT, SPRING RETAINER
-
68409-055 SCREW, CAPSCREW, CAP
-
78428-002 NUT, LOCKNUT, LOCK
-
80503-432 A-ARM, UPPER RIGHT - BLACK (INC. 9-12)A-ARM, UPPER RIGHT - BLACK (INC. 9-12)
-
80503-433 A-ARM, UPPER LEFT - BLACK (INC. 9-12)A-ARM, UPPER LEFT - BLACK (INC. 9-12)
-
90403-208 ...BUSHING...BUSHING
-
100403-214 ...AXLE...AXLE
-
110423-009 ...RING, RETAINING...RING, RETAINING
-
120405-483 ...BALL JOINT...BALL JOINT
-
130423-946 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
141502-594 CLAMP, ROUTINGCLAMP, ROUTING
-
158409-075 SCREW, CAPSCREW, CAP
-
160503-376 A-ARM, LOWER RIGHT - BLACK (INC. 9-12)A-ARM, LOWER RIGHT - BLACK (INC. 9-12)
-
160503-377 A-ARM, LOWER LEFT - BLACK (INC. 9-12)A-ARM, LOWER LEFT - BLACK (INC. 9-12)
-
171406-034 GUARD, BOOT - RIGHT - BLACKGUARD, BOOT - RIGHT - BLACK
-
171406-035 GUARD, BOOT - LEFT - BLACKGUARD, BOOT - LEFT - BLACK
-
180423-545 SCREW, SHOULDERSCREW, SHOULDER
-
191502-803 AXLE - FRONT - RIGHT (INC. 20-23)AXLE - FRONT - RIGHT (INC. 20-23)
-
191502-802 AXLE - FRONT - LOCKING - LEFT (INC. 20-23)AXLE - FRONT - LOCKING - LEFT (INC. 20-23)
-
201436-419 ...REPAIR KIT, BOOT (INC. 21)...REPAIR KIT, BOOT (INC. 21)
-
211441-988 ......CLIP, RETAINING......CLIP, RETAINING
-
221402-885 ...PIN, DETENT...PIN, DETENT
-
231402-889 ...CLIP, RETAINING...CLIP, RETAINING
-
240505-580 KNUCKLE - ASSEMBLY - RIGHT (INC. 25-26)KNUCKLE - ASSEMBLY - RIGHT (INC. 25-26)
-
240505-581 KNUCKLE - ASSEMBLY - LEFT (INC. 25-26)KNUCKLE - ASSEMBLY - LEFT (INC. 25-26)
-
251402-809 ...BEARING...BEARING
-
260423-423 ...RING, RETAINING...RING, RETAINING
-
270423-998 SCREW, SHOULDERSCREW, SHOULDER
