GEAR SHIFTING ASSEMBLY для Arctic Cat PROWLER 1000 XTZ 4X4 [U2014P4W1POSE] (INTERNATIONAL) - 2014 года выпуска
-
№АртикулНазвание
-
18470-516 SCREW, MACHINESCREW, MACHINE
-
20409-091 SWITCH, GEAR POSITIONSWITCH, GEAR POSITION
-
30818-013 CONTACTCONTACT
-
40818-017 SPRINGSPRING
-
50828-040 WASHERWASHER
-
60818-127 SHAFT, GEAR SHIFT - ASSEMBLYSHAFT, GEAR SHIFT - ASSEMBLY
-
70828-131 SPACERSPACER
-
80818-055 CAM, GEAR SHIFTCAM, GEAR SHIFT
-
90826-006 SCREW, CAPSCREW, CAP
-
100828-036 WASHERWASHER
-
110831-010 RING, RETAININGRING, RETAINING
-
120818-095 SHAFT, SUB-GEAR SHIFTSHAFT, SUB-GEAR SHIFT
-
130818-014 ARM, SHIFTARM, SHIFT
-
148468-620 SCREW, MACHINESCREW, MACHINE
-
150828-038 WASHERWASHER
-
160818-002 STOPPER, CAMSTOPPER, CAM
-
170818-004 SUPPORT, CAM STOPPERSUPPORT, CAM STOPPER
-
180818-090 SPRINGSPRING
-
190828-035 WASHERWASHER
-
208424-602 NUTNUT
-
210818-072 FORK, SHIFTFORK, SHIFT
-
220818-006 SHAFT, SHIFT FORKSHAFT, SHIFT FORK
