SHIFTER ASSEMBLY для Arctic Cat PROWLER 1000 XTZ 4X4 [U2014P4W1POSE] (INTERNATIONAL) - 2014 года выпуска
-
№АртикулНазвание
-
11502-516 MOUNT, SHIFT - BLACKMOUNT, SHIFT - BLACK
-
28476-620 SCREW, MACHINESCREW, MACHINE
-
30423-577 CLIP, U-NUTCLIP, U-NUT
-
48477-616 SCREW, MACHINESCREW, MACHINE
-
51402-275 RETAINER, SHIFT LINKAGERETAINER, SHIFT LINKAGE
-
62402-005 KNOB, SHIFTKNOB, SHIFT
-
70423-885 NUTNUT
-
81502-510 LEVER, SHIFTLEVER, SHIFT
-
91402-880 SPRINGSPRING
-
100423-505 SCREW, SHOULDERSCREW, SHOULDER
-
111502-666 AXLE, SHIFTAXLE, SHIFT
-
128424-802 NUTNUT
-
138427-602 NUT, LOCKNUT, LOCK
-
140487-063 CABLE, SHIFTCABLE, SHIFT
-
150423-356 SCREW, SHOULDERSCREW, SHOULDER
-
162516-609 BRACKET, SHIFT CABLEBRACKET, SHIFT CABLE
-
178468-635 SCREW, MACHINESCREW, MACHINE
-
180124-057 E-RINGE-RING
