AIR INTAKE ASSEMBLY для Arctic Cat VLX 700 CAMO - 2017 года выпуска
-
№АртикулНазвание
-
10470-877 AIR BOX, TOPAIR BOX, TOP
-
20470-560 SCREEN, AIR FILTERSCREEN, AIR FILTER
-
30470-558 FILTER, AIRFILTER, AIR
-
40470-728 HOUSING, AIR INTAKEHOUSING, AIR INTAKE
-
50423-455 CLIP, SPRINGCLIP, SPRING
-
61470-184 DUCT, ENGINE INTAKEDUCT, ENGINE INTAKE
-
70470-729 BOOTBOOT
-
80423-342 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
90423-019 CLAMPCLAMP
-
100470-442 VALVE, DRAINVALVE, DRAIN
-
110410-172 HOSE, VENT - CRANKCASEHOSE, VENT - CRANKCASE
-
121623-281 CLAMP, HOSECLAMP, HOSE
-
130423-766 CAP, DRAINCAP, DRAIN
-
141623-287 CLAMP, HOSECLAMP, HOSE
-
150423-554 CLAMPCLAMP
-
160470-511 BOOT, INTAKEBOOT, INTAKE
-
170430-055 SENSOR, AIR TEMPERATURE (INC. 18)SENSOR, AIR TEMPERATURE (INC. 18)
-
185507-224 ...O-RING...O-RING
-
192406-604 PANEL, SHIELDPANEL, SHIELD
-
200623-362 CLIP, RETAININGCLIP, RETAINING
