HANDLEBAR AND CONTROLS для Arctic Cat AC F5 EFI - 2009 года выпуска
-
№АртикулНазвание
-
10123-811 TIE, CABLE - 4 IN.TIE, CABLE - 4 IN.
-
20123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
34606-945 GRIP, HANDLEBARGRIP, HANDLEBAR
-
40609-826 CONTROL, THROTTLE - REAR (INC. 5-10)CONTROL, THROTTLE - REAR (INC. 5-10)
-
50609-859 ...KIT, THROTTLE LEVER MOUNTING (INC. 6-9)...KIT, THROTTLE LEVER MOUNTING (INC. 6-9)
-
90123-766 ......NUT, PUSH......NUT, PUSH
-
100609-795 ...LEVER, THROTTLE...LEVER, THROTTLE
-
110617-248 PAD, INSULATORPAD, INSULATOR
-
120609-775 ELEMENT, THUMBWARMERELEMENT, THUMBWARMER
-
130609-595 CLIP, RETAININGCLIP, RETAINING
-
140609-864 CONTROL, THROTTLE - FRONTCONTROL, THROTTLE - FRONT
-
150609-792 COVER, CONNECTORCOVER, CONNECTOR
-
160609-793 SCREW, MACHINESCREW, MACHINE
-
170609-791 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
180609-805 CONTROL, DIMMER - FRONTCONTROL, DIMMER - FRONT
-
190609-811 CONTROL, DIMMER - REARCONTROL, DIMMER - REAR
-
200609-828 ELEMENT, HANDWARMER - RIGHTELEMENT, HANDWARMER - RIGHT
-
200609-829 ELEMENT, HANDWARMER - LEFTELEMENT, HANDWARMER - LEFT
-
211705-092 HANDLEBARHANDLEBAR
-
221705-286 WRAP, HANDLEBAR PADWRAP, HANDLEBAR PAD
-
230619-926 FOAM, HANDLEBAR PADFOAM, HANDLEBAR PAD
-
241686-458 HARNESS, HANDLEBARHARNESS, HANDLEBAR
-
250687-212 CABLE, THROTTLECABLE, THROTTLE
-
260124-057 E-RINGE-RING
-
270124-056 WASHERWASHER
