FUEL PUMP ASSEMBLY для Arctic Cat SNO PRO 500 - 2012 года выпуска
-
№АртикулНазвание
-
10423-898 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
26606-176 GUARD, FITTING - FUEL PUMPGUARD, FITTING - FUEL PUMP
-
32670-042 PLATE, RETAINING - FUEL PUMPPLATE, RETAINING - FUEL PUMP
-
42670-131 PUMP, FUEL - ASSEMBLY (INC. 5)PUMP, FUEL - ASSEMBLY (INC. 5)
-
52670-235 ...FLOAT...FLOAT
-
60470-838 SEALSEAL
-
72670-205 PICKUP, FUEL - ASSEMBLY (INC. 8 AND SEVEN NO. 9)PICKUP, FUEL - ASSEMBLY (INC. 8 AND SEVEN NO. 9)
-
80610-691 ...HOSE, GASLINE - 10 FT...HOSE, GASLINE - 10 FT
-
90610-563 ...CLAMP, HOSE...CLAMP, HOSE
-
102670-141 FITTING, QUICK-CONNECTFITTING, QUICK-CONNECT
-
111619-349 CONDUIT, FLEXIBLE - 5 FTCONDUIT, FLEXIBLE - 5 FT
-
120123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
131623-832 FITTING, ADAPTERFITTING, ADAPTER
-
140610-419 CLAMP, HOSECLAMP, HOSE
-
150610-818 HOSE, GASLINEHOSE, GASLINE
-
160623-373 CLAMP, HOSECLAMP, HOSE
