SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat XF 7000 CROSSTOUR ORANGE - 2017 года выпуска

№

Артикул

Название
1

5718-014 PANEL, SIDE - RIGHT - W/DECALS - BLACK (INC. 2-7, 14-17, 24-27)

PANEL, SIDE - RIGHT - W/DECALS - BLACK (INC. 2-7, 14-17, 24-27)

53 240 ₽
2

3718-312 ...PANEL, SIDE W/O DECALS - RIGHT - BLACK (INC. 3-7, 24-27)

...PANEL, SIDE W/O DECALS - RIGHT - BLACK (INC. 3-7, 24-27)

38 680 ₽
3

0617-626 ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT

......FOAM, SIDE PANEL - UPPER FRONT - RIGHT

650 ₽
4

6606-414 ......FOIL, PROTECTIVE - MIDDLE - RIGHT

......FOIL, PROTECTIVE - MIDDLE - RIGHT

290 ₽
5

0617-628 ......FOAM, SIDE PANEL - UPPER REAR - RIGHT

......FOAM, SIDE PANEL - UPPER REAR - RIGHT

5 400 ₽
6

0617-632 ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT

......FOAM, SIDE PANEL - LOWER FRONT - RIGHT

3 320 ₽
7

6606-416 ......FOIL, PROTECTIVE - LOWER SIDE - REAR - RIGHT

......FOIL, PROTECTIVE - LOWER SIDE - REAR - RIGHT

540 ₽
8

5718-015 PANEL, SIDE - LEFT - W/DECALS - BLACK (INC. 9-19, 23-27)

PANEL, SIDE - LEFT - W/DECALS - BLACK (INC. 9-19, 23-27)

53 240 ₽
9

4718-101 ...PANEL, SIDE W/O DECALS - LEFT - BLACK (INC. 10-13, 18-19, 23-27)

...PANEL, SIDE W/O DECALS - LEFT - BLACK (INC. 10-13, 18-19, 23-27)

39 930 ₽
10

0617-629 ......FOAM, SIDE PANEL - UPPER REAR - LEFT

......FOAM, SIDE PANEL - UPPER REAR - LEFT

2 490 ₽
11

0617-635 ......FOAM, SIDE PANEL - LOWER REAR - LEFT

......FOAM, SIDE PANEL - LOWER REAR - LEFT

1 870 ₽
12

0617-631 ......FOAM, SIDE PANEL - CENTER FRONT - LEFT

......FOAM, SIDE PANEL - CENTER FRONT - LEFT

650 ₽
13

0617-681 ......FOAM, SIDE PANEL - LOWER FRONT - LEFT

......FOAM, SIDE PANEL - LOWER FRONT - LEFT

860 ₽
14

3621-300 ...DECAL, SIDE PANEL - UPPER - RIGHT

...DECAL, SIDE PANEL - UPPER - RIGHT

8 310 ₽
14

3621-301 ...DECAL, SIDE PANEL - UPPER - LEFT

...DECAL, SIDE PANEL - UPPER - LEFT

8 310 ₽
15

3621-306 ...DECAL, SIDE PANEL - LOWER REAR - RIGHT

...DECAL, SIDE PANEL - LOWER REAR - RIGHT

6 860 ₽
15

3621-307 ...DECAL, SIDE PANEL - LOWER REAR - LEFT

...DECAL, SIDE PANEL - LOWER REAR - LEFT

6 860 ₽
16

3621-304 ...DECAL, SIDE PANEL - FRONT - RIGHT

...DECAL, SIDE PANEL - FRONT - RIGHT

2 070 ₽
16

3621-305 ...DECAL, SIDE PANEL - FRONT - LEFT

...DECAL, SIDE PANEL - FRONT - LEFT

2 070 ₽
17

3621-302 ...DECAL, SIDE PANEL - MID - RIGHT

...DECAL, SIDE PANEL - MID - RIGHT

2 070 ₽
17

3621-303 ...DECAL, SIDE PANEL - MID - LEFT

...DECAL, SIDE PANEL - MID - LEFT

2 070 ₽
18

2602-704 ...SCREEN, VENT

...SCREEN, VENT

2 910 ₽
19

0623-269 ...CLIP, RETAINING

...CLIP, RETAINING

190 ₽
20

2602-711 DEFLECTOR, AIR

DEFLECTOR, AIR

2 910 ₽
21

0623-797 SCREW, SELF-TAPPING

SCREW, SELF-TAPPING

650 ₽
22

2602-703 RETAINER, AIR DEFLECTOR

RETAINER, AIR DEFLECTOR

1 870 ₽
23

1623-637 CLIP, U-NUT

CLIP, U-NUT

380 ₽
24

0607-447 CABLE

CABLE

810 ₽
25

0605-283 CLIP, HAIRPIN

CLIP, HAIRPIN

190 ₽
26

8060-486 RIVET

RIVET

60 ₽
27

8050-127 WASHER

WASHER

210 ₽
28

0619-206 FOIL, PROTECTIVE (OPT.)

FOIL, PROTECTIVE (OPT.)

34 730 ₽
29

5706-531 SCREEN, INTAKE - (OPT.)

SCREEN, INTAKE - (OPT.)

3 110 ₽
30

1702-369 DUCT, BELT COOLING

DUCT, BELT COOLING

5 820 ₽
31

1623-030 CLIP, U-NUT

CLIP, U-NUT

150 ₽
32

5718-016 PLATE, SKID - RIGHT W/DECALS - BLACK (INC. 33-36, 45 AND 46)

PLATE, SKID - RIGHT W/DECALS - BLACK (INC. 33-36, 45 AND 46)

25 790 ₽
33

3718-788 ...PLATE, SKID - W/O DECALS - RIGHT - BLACK (INC. 34-36)

...PLATE, SKID - W/O DECALS - RIGHT - BLACK (INC. 34-36)

24 950 ₽
34

0617-640 ......FOAM, SKID PLATE - UPPER REAR - RIGHT

......FOAM, SKID PLATE - UPPER REAR - RIGHT

540 ₽
35

0617-638 ......FOAM, SKID PLATE - CENTER FRONT - RIGHT

......FOAM, SKID PLATE - CENTER FRONT - RIGHT

6 440 ₽
36

0617-636 ......FOAM, SKID PLATE - UPPER FRONT - RIGHT

......FOAM, SKID PLATE - UPPER FRONT - RIGHT

5 400 ₽
37

8061-708 RIVET

RIVET

150 ₽
38

5718-017 PLATE, SKID - LEFT W/DECALS - BLACK (INC. 37 AND 39-46)

PLATE, SKID - LEFT W/DECALS - BLACK (INC. 37 AND 39-46)

25 790 ₽
39

3718-789 ...PLATE, SKID - LEFT W/FOAM - BLACK (INC. 37, 40-44)

...PLATE, SKID - LEFT W/FOAM - BLACK (INC. 37, 40-44)

16 430 ₽
40

0617-637 ......FOAM, SKID PLATE - UPPER FRONT - LEFT

......FOAM, SKID PLATE - UPPER FRONT - LEFT

2 490 ₽
41

0617-639 ......FOAM, SKID PLATE - CENTER FRONT - LEFT

......FOAM, SKID PLATE - CENTER FRONT - LEFT

2 490 ₽
42

0617-641 ......FOAM, SKID PLATE - UPPER REAR - LEFT

......FOAM, SKID PLATE - UPPER REAR - LEFT

610 ₽
43

0123-802 WASHER

WASHER

20 ₽
44

6606-613 PANEL, REINFORCEMENT

PANEL, REINFORCEMENT

1 870 ₽
45

3621-308 DECAL, SKID PLATE - FRONT - RIGHT

DECAL, SKID PLATE - FRONT - RIGHT

1 660 ₽
45

3621-309 DECAL, SKID PLATE - FRONT - LEFT

DECAL, SKID PLATE - FRONT - LEFT

1 660 ₽
46

3621-310 DECAL, SKID PLATE - FRONT - RIGHT

DECAL, SKID PLATE - FRONT - RIGHT

920 ₽
46

3621-311 DECAL, SKID PLATE - REAR - RIGHT

DECAL, SKID PLATE - REAR - RIGHT

920 ₽
47

2623-005 CLIP, RETAINING

CLIP, RETAINING

400 ₽
48

6606-592 PIN, RETAINING

PIN, RETAINING

540 ₽
49

1623-129 SCREW, SELF-TAPPING

SCREW, SELF-TAPPING

230 ₽
50

2612-685 PLATE, EXHAUST OUTLET

PLATE, EXHAUST OUTLET

8 730 ₽
51

2612-964 SEAL, EXHAUST OUTLET

SEAL, EXHAUST OUTLET

1 870 ₽
52

8061-508 RIVET

RIVET

110 ₽
53

6606-342 FASCIA, FRONT - RIGHT - BLACK

FASCIA, FRONT - RIGHT - BLACK

2 910 ₽
53

6606-579 FASCIA, FRONT LEFT - BLACK

FASCIA, FRONT LEFT - BLACK

5 190 ₽
54

0623-784 SCREW, SELF-TAPPING

SCREW, SELF-TAPPING

210 ₽
