FUEL PUMP ASSEMBLY для Arctic Cat ZR 5000 LXR 137 BLACK - 2017 года выпуска
-
№АртикулНазвание
-
10423-898 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
22670-042 PLATE, RETAINING - FUEL PUMPPLATE, RETAINING - FUEL PUMP
-
32670-476 PUMP, FUEL - ASSEMBLY (INC. 4)PUMP, FUEL - ASSEMBLY (INC. 4)
-
42670-235 ...FLOAT...FLOAT
-
50470-838 SEALSEAL
-
61770-170 FUEL LEVEL SENSOR KITFUEL LEVEL SENSOR KIT
-
72670-377 PICKUP, FUEL - ASSEMBLYPICKUP, FUEL - ASSEMBLY
-
80610-563 CLAMP, HOSECLAMP, HOSE
-
92670-442 HOSE, FUEL PUMP/PICKUPHOSE, FUEL PUMP/PICKUP
-
102670-141 FITTING, QUICK-CONNECTFITTING, QUICK-CONNECT
-
110610-875 HOSE, GASLINE - PUMP/FILTERHOSE, GASLINE - PUMP/FILTER
-
121670-825 FILTER, FUELFILTER, FUEL
-
120123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
130623-751 TIE, CABLE - REUSABLETIE, CABLE - REUSABLE
-
140610-873 HOSE, GASLINE - FILTER/THROTTLE BODYHOSE, GASLINE - FILTER/THROTTLE BODY
-
150619-776 CONDUIT, FLEXIBLE - 5 FTCONDUIT, FLEXIBLE - 5 FT
-
160610-419 CLAMP, HOSECLAMP, HOSE
